TELECO AUTOMATION TVRDS868B01 Installer Instruction Manual page 12

4.4 Four channels memorization
Memorization of four button transmitter in one step.
6x
P2
continuous sound
4.5 Remote memorization of the first transmitter
The memory must to be empty in order to perform this procedure
The added transmitter will have the double-channel function.
P3 button is
located inside the
transmitter
ON
Press once P3 button of a transmitter for 2
sec. within 30 seconds from power on.
The buzzer emits a continuous sound.
4.6 Remote memorization of further transmitters
The added transmitter will have the same functions of the transmitter used for the memorization.
This procedure is compatible with any type of transmitter.
P3 button is
located inside the
transmitter
P3
memorized
Press once P3 button (twice if
within 30 seconds from power
on) of a memorized transmitter
for 2 sec. The buzzer emits a
continuous sound.
keep it pressed
( )
button to
memorize
intermittent sound
new
P3
continuous
sound memorized
< 5 s
Press the button of a transmitter
already memorized. The buzzer
stops for 1 second, then sound
continously again.
LIGHT ON - LIGHT OFF ►
Press P2 six times and keep it pressed.
The buzzer emits a continuous sound.
Press any button of the transmitter to memorize.
Once the memorization is successfully completed,
...
the buzzer emits a fast intermittent sound.
continuous
sound
< 5 s
Press any button of the pair to memorize. Once
the memorization is successfully completed,
the buzzer emits a fast intermittent sound.
continuous
sound
1 s
Press the button of a new transmitter to memorize
with the same functions. Once the memorization
is successfully completed, the buzzer emits a fast
intermittent sound.
12
OPEN ►
CLOSE ►
STOP ►
OPEN (STOP) ►
.
CLOSE (STOP) ►
intermittent sound
...
new intermittent sound
< 5 s
...
