Installing the Wall Control
11
Wall Controller 1
HOT IN
1. Install the wall control using the wiring diagram above.
2. Individually pair each of the wall controls with the fan receiver using the pairing instruction.
16
Wall Controller 2
Green
if Applicable
Wall Controller 3
White to Fan
Black to Fan
Green to Fan
F R -W 200 1
