Setup Instructions:
A) Use standoff screws to secure the front panel and
back panel of the pedestal to the side panels.
B) After assembling front, back, and side panels,
slide shelf into place. The shelf will sit on pins on the
inside of the side panels.
C) Set counter top on top of assembled pedestal base.
Shelf sits on
shelf pins.
w w w . c l a s s i c e x h i b i t s . c o m
WHEN DISASSEMBLING ALUMINUM EXTRUSION, TIGHTEN ALL
SETSCREWS AND LOCKS TO PREVENT LOSS DURING SHIPPING
Attach the oval counter
top to the pedestal base.
Front Panel
Standoff
Screw
Step 1
866.652.2100
© 2015
Page 1 of 4
