Classic Exhibits visionary DESIGNS 38907 Setup Instructions

Hide thumbs

Advertisement

Quick Links

Download this manual
Step 1
Order #38907 - General Layout
866.652.2100
10'
Plan View
20'
WHEN DISASSEMBLING ALUMINUM EXTRUSION, TIGHTEN ALL
SETSCREWS AND LOCKS TO PREVENT LOSS DURING SHIPPING
© 2013
w w w . c l a s s i c e x h i b i t s . c o m
Page 1 of 6

Advertisement

loading
Need help?

Need help?

Do you have a question about the visionary DESIGNS 38907 and is the answer not in the manual?

Questions and answers

Related Manuals for Classic Exhibits visionary DESIGNS 38907

Summary of Contents for Classic Exhibits visionary DESIGNS 38907

  • Page 1 Step 1 Order #38907 - General Layout 866.652.2100 10’ Plan View 20’ WHEN DISASSEMBLING ALUMINUM EXTRUSION, TIGHTEN ALL SETSCREWS AND LOCKS TO PREVENT LOSS DURING SHIPPING © 2013 w w w . c l a s s i c e x h i b i t s . c o m Page 1 of 6...
  • Page 2 Step 2 Order #38907 - General Information 866.652.2100 Using Your Setup Instructions The Visionary Designs Setup Instructions are created specifically for your Detail A configuration. They are laid out sequentially, including an exploded view of the entire display, and then a logical series of detailed steps to assemble the main structure and components.
  • Page 3 Step 1 Order #38907 - Backwall Assembly 866.652.2100 Item Description Steps: Base Plate 1) Attach lower verticals [2,3,4,5] to base plates [1]. 2) Attach upper verticals [2a,3a,4a,5a] to lower verticals [2,3,4,5]. 2/2a 42” RR91 Vertical Extrusion 3) Connect horizontals [6a,6b] and [7a,7b] together. 3/3a 42”...
  • Page 4 Step 2 Order #38907 - Backwall Circle Assembly 866.652.2100 Item Description 10a/10b 1/1 5.06” Z45 Vertical Extrusion 47.56” Z45 Curved Extrusion 47.56” Z45 Curved Extrusion 47.56” Z45 Curved Extrusion 47.56” Z45 Curved Extrusion 47.56” Z45 Curved Extrusion 47.56” Z45 Curved Extrusion Attach graphics velcro on back of...
  • Page 5 Step 3 Order #38907 - Canopy Assembly 866.652.2100 Using Your Setup Instructions The Aero Canopy Setup Instructions are created specifically for your configuration. They include an exploded view of the frame which is sequentially numbered. We encourage you to study the instructions before attempting to assemble your exhibit.
  • Page 6 Step 4 Order #38907 - Backwall Attachments 866.652.2100 Swivel iPad Clamshell Connectors Attachment Steps: 1) Connect iPad clamshells to backwall where indicated, as shown in detail. iPad Mount Slide connectors into groove of extrusion. Tighten setscrew to secure in place. Attach monitor mount to connectors with screws.
  • Page 7 Step 5 Order #38907 - Pedestal Assembly 866.652.2100 Item Description Steps: 38” S40 Vertical Extrusion w/ Door Hinge 1) Connect horizontals [19] to verticals [17,18] inserting infills as shown. 2) Connect horizontals [19] to extrusions on backside of front panel. 38”...
  • Page 8 Step 6 Order #38907 - iPad Kiosk Assembly 866.652.2100 Nuts Lock Lock Lock Square Clam Shell Plate iPad Wire Stand Access Steps: 1) Slide infill between stand verticals as shown. Infill 2) Attach horizontal [2] between stand verticals. 3) Attach base [1] to stand verticals using bolts. 4) Attach square plate [3] to stand using bolt.
  • Page 9 Order #38907 - Case Packing - Case 1 of 5 866.652.2100 Top View of Each Level Setup Hardware Base Plate Lights Base Plate Level 1 Level 2 WHEN DISASSEMBLING ALUMINUM EXTRUSION, TIGHTEN ALL SETSCREWS AND LOCKS TO PREVENT LOSS DURING SHIPPING ©...

  • Page 10: Level 1

    Order #38907 - Case Packing - Case 2 of 5 866.652.2100 Top View of Each Level Graphics Connectors (3) 10a, 6a,6a, 6b,6b, 7a,7a 7b,7b 8b 8a Level 1 Level 2 WHEN DISASSEMBLING ALUMINUM EXTRUSION, TIGHTEN ALL SETSCREWS AND LOCKS TO PREVENT LOSS DURING SHIPPING ©...
  • Page 11 Order #38907 - Case Packing - Case 3 of 5 866.652.2100 Top View of Each Level Canopy Level 1 Level 2 Level 3 WHEN DISASSEMBLING ALUMINUM EXTRUSION, TIGHTEN ALL SETSCREWS AND LOCKS TO PREVENT LOSS DURING SHIPPING © 2013 w w w . c l a s s i c e x h i b i t s . c o m...
  • Page 12 Order #38907 - Case Packing - Case 4 of 5 866.652.2100 Top View of Each Level Shelf Pedestal Front Assembled Pedestal Infills Door Panel Counter Top 19 (3) Level 4 Level 1 Level 2 Level 3 WHEN DISASSEMBLING ALUMINUM EXTRUSION, TIGHTEN ALL SETSCREWS AND LOCKS TO PREVENT LOSS DURING SHIPPING ©...

  • Page 13: Base Plate

    Order #38907 - Case Packing - Case 5 of 5 866.652.2100 Top View of Each Level Setup Hardware Base Plate Assembled iPad Kiosk Base Lit Rack Connectors Literature Rack Mounting Plate Literature Clam Rack Shell Level 1 Level 2 WHEN DISASSEMBLING ALUMINUM EXTRUSION, TIGHTEN ALL SETSCREWS AND LOCKS TO PREVENT LOSS DURING SHIPPING ©...
