Order #xxxxx - LTK-0 - Pedestal Assembly
Item Number
Description
1
16.25"w x 38"h Panel
2
38"h Flexible Connector
3
23"w x 38"h Panel w/ Door
4
6.625"w x 38"h Panel
5
38"h Flexible Connector
6
16.25"w x 38"h Panel
7
38"h 90° Connector
8
57.5°r Curved Panel
9
57.5°r Curved Panel
10
38"h 90° Connector
2
1
10
w w w . c l a s s i c e x h i b i t s . c o m
NOTE :
PDF copies of your Setup Instructions are available @ www.classicexhibits.com
Use the Search Tool located on the lower left-hand corner of the Classic Home page.
Enter your 5-7 digit Order #.
Steps:
1) Assemble by starting at panel
2) Velcro internal shelf supports to inside of assembled base.
3) Set internal shelf atop shelf supports.
4) Place counter atop assembled pedestal base.
5) Attach top shelf to counter using stand-offs.
4
3
Door
Internal Shelf
8
9
WHEN DISASSEMBLING ALUMINUM EXTRUSION, TIGHTEN ALL
SETSCREWS AND LOCKS TO PREVENT LOSS DURING SHIPPING
Search for Setup Instructions
search
#1
and continue in numerical order.
5
6
7
Plex Shelf
Place counter atop assembled
pedestal base. Attach top
Counter Top
shelf to counter using stand-offs.
Step
866.652.200
© 2009
