Atdec ADBS-4x1-39TW Install Manualline

4 x 1 Wall Menu Board Tilt
INSTALL GUIDELINES
TWO PERSON INSTALL RECOMMENDED.
• Read and understand Installation Safety Instructions before commencing installation.
• Atdec recommends that a professional AV installer or other suitably qualified person
install this product.
• Configurations should be installed in a symmetrical manner for optimal safety.
• Place rail supports (ADB-RPJ, ADB-RUJ, ADB-WP) evenly along the length of a Rail
segment to provide even loading of components.
• ADB-R175 requires two rail supports (ADB-RPJ, ADB-RUJ, ADB-WP) to support a load
of 200lbs (100kg). If one rail support is used, the rail can only support 110lbs (50kg)
maximum load.
• Fasten ADB-RX symmetrically over the junction of Rail segments. Tighten the set screws
of ADB-RX firmly.
• Place ADB-WP Wall Plates directly behind the centre of each screen.
• ADB-RX must never be used as the sole support for any Rail segment. The ADB-RX is for
alignment purposes only and is not to bear load. All Rail segments must be supported by
at least one ADB-WP Wall Plate.
• When attaching displays, attach in an order that ensures stability during installation.
Alternate the loading order such that loads are balanced across to system. Alternate
the side onto which screens are placed to distribute load evenly.
• ADB-R48 must be placed in the centre of the rail segments and supported by an
ADB-WP Wall Plate.
Installation Guide
ADBS-4x1-39TW

REQUIRED TOOLS

• Power driver
• 13mm Hex socket
• Crosshead Screwdriver

OPTIONAL TOOLS

• Spirit Level
ADBS-4x1-39TW Page 1 of 4
