How to Measure Automatically

Push the Measure button to display the menu for the settings of the Automatic
Measurements. At most 8 types of measurements could be displayed on the bottom
left of the screen.
The oscilloscopes provide 31 parameters for auto measurement, including Period,
Frequency, Mean, PK-PK, RMS, Max, Min, Top, Base, Amplitude, Overshoot,
Preshoot, Rise Time, Fall Time, +PulseWidth, -PulseWidth, +Duty Cycle, -Duty
Cycle, Delay A→B , Delay A→B , Cycle RMS, Cursor RMS, Screen Duty,
Phase A→B , Phase A→B
FallEdgeCnt, Area, and Cycle Area.
The "Automatic Measurements" menu is described as the following table:
Function Menu
Meas Type
(left menu)
Source
Add CH1 CH2
CH3 CH4
Add
Meas Type
(left menu)
Remove
Remove
Remove All Remove all the measures
ON
Snapshot
OFF
CH1
CH2
Source
CH3
CH4
Measure
Only if the waveform channel is in the ON state, the measurement can be performed.
User Manual
button to power on the instrument.
, +PulseCount, -PulseCount, RiseEdgeCnt,
Description
Select the measure types
Select the source
Add the selected measure types (shown at the left
bottom, you could only add 8 types at most)
Select the types need to be deleted.
The selected type and source are shown in the
Remove menu on the right.
Remove the selected measure type
Show all the measures of the snapshot source
Turn off the snapshot
Select the snapshot source
