TD-W8968
2. Click the Add button on the screen Figure 4-7 and the next configuration is similar to IPoE
(see section 4.5.2.2
Static IP Address on the screen of Figure 4-15, and the Static IP Address for DNS Server on
the screen of Figure 4-18.
Note:
ETH and ATM service can not coexist. If the ATM Interface had configured, you cannot configure
any other WAN service over the ETH Interface until the ATM Interface is deleted.
4.5.2.6 ETH-PPPoE
If your ISP provides a PPPoE connection, click the Add button on the screen Figure 4-7 and the
following configuration is similar to PPPoE over ATM interface (see section
ATM-EoA-PPPoE).
4.5.2.7 ETH-IPoE
If your ISP provides an IPoE connection, click the Add button on the screen Figure 4-7 and the
next configuration is similar to IPoE over ATM interface (see section
4.5.2.8 ETH-Bridge
If you want to adopt the Bridge service, click the Add button on the screen Figure 4-7 and the next
configuration is similar to Bridge over ATM interface (see section
4.5.3 3G Settings
Choose menu "Advanced Setup→3G Settings", you can configure parameters for 3G function
on the screen below. To use the 3G function, you should first insert your USB modem on the USB
port of the modem router. There is already much 3G USB modem information embedded in the
modem router. The USB modem parameters will be set automatically if the card is supported by
the modem router. If your USB modem inserted is supported by the modem router, then "Identify
successfully" will display in the USB 3G Modem field as shown in Figure 4-20.
Some 3G USB modem may not be supported by the modem router. For more information, please
refer to Compatibility List on our website: www.tp-link.com. If your 3G USB modem is
incompatible with our modem router, please feel free to contact our
300Mbps Wireless N USB ADSL2+ Modem Router User Guide
ATM-EoA-IPoE). The difference is that you have to manually set the
28
4.5.2.2 ATM-EoA-IPoE).
4.5.2.3 ATM-EoA-Bridg).
technical support.
4.5.2.1
