TD-W8968
Remove All: Click Remove All, then all the interface in the table will be deleted.
Remove: Select the check box in the table above and then click Remove, the corresponding
interface will be deleted in the table.
4.5.2.2 ATM-EoA-IPoE
If your ISP provides an IPoE connection and you need to use an ATM Interface, follow the steps
below to add a WAN service over a selected ATM interface:
1. Add a new ATM interface and select EoA option for DSL Link Type
2. Click the Add button on the screen (as shown Figure 4-7). Select WAN Service Interface over
ATM PVC on the next screen (as shown Figure 4-8).
3. If your ISP provides an IPoE connection, select IPoE option for the WAN service type on the
screen (as shown Figure 4-9), and click Next button to continue.
4. Enter parameters in the following blanks to configure the WAN IP Address and click Next.
Obtain an IP address automatically: Select this option, the modem router will be able to
obtain IP network information dynamically from a DHCP server provided by your ISP.
Note:
1) The response message from a DHCP server typically contains a number of configuration
parameters (DHCP options) for the modem router. The DHCP options include IP network
300Mbps Wireless N USB ADSL2+ Modem Router User Guide
Figure 4-14
Figure 4-15
24
(4.5.1.1 ATM Interface).
