TD-W8968

300Mbps Wireless N USB ADSL2+ Modem Router User Guide

Chapter 4. Configuring the Modem Router

This chapter will show each Web page's key function and the configuration way.

After your successful login, you will see the eight main menus on the left of the Web-based utility.

On the right, there are the corresponding explanations and instructions.

The detailed explanations for each Web page's key function are listed below.

Choose "Device Info" menu, there are six submenus under the main menu: Summary, WAN,

Statistics, Route, ARP and DHCP. This Device Info section mainly introduces the elementary

information about the modem router and its current settings in use. Click any of them, and you will

be able to view the corresponding information.

Choose "Device Info" "Summary", you will see the Summary screen (shown in Figure 4-1). The

first table indicates the information about the version including Software and Hardware. The

second table displays the current status of the Internet connection. This information will vary

depending on the settings of the modem router configured on the Advanced Setup screen.
