02
Input Voltage
Output Voltage
Stroke
Weight Capacity
Speed
Height Range
Duty Cycle
Material
Certification
Minimum Table Top Size
Feature
Soft Start and Stop
Memory Presets
*When using the FLT-10with the included control box, the stroke size will be 24.5" due to the safety feature built into
the control box.
Description
The tablelift will accelerate to maximum speed and
deccelerate to a stop to ensure smooth travel.
The Smart Remote has the ability to save preset height locations
for convenience. Set the numbered buttons on the Smart Remote
for quick and seamless adjustment.
Specifications
120 VAC, 60 Hz
24 VDC
25.5"
350lbs (175 lbs Per Leg)
1.5"/sec
22" - 47.5" (without table top)
10% Max. 2 mins on, 18 mins off
Steel
UL
43"x 24"
