7.25"
3"
*Drawing not to Scale. All Measurements are Approximate
Luxier USA
Single Handle Bathroom Lavatory Faucet
Model Number:
BSH06-SB
BSH06-SC
2.3"
1 3/8" Hole Size
Features:
- Brass Construction
- Single Hole Installation
- Drip Free Ceramic Cartridge
- NEOPERL
aerator 1.2 gpm max at 60 psi
®
- Complies with:
NSF 61-9
ASME A112.18.1 / CSA B125.1
IAPMO / UPC / cUPC
CA AB-1953
WaterSense
CALGreen
7"
3.56"
5.56"
Approx. 24" water supply hose
3/8" compression tting
1
2.56"
Max. Deck Thickness 2"
BSH06S Rev. A 02/2017
Advertisement
Table of Contents
Related Manuals for Luxier BSH06-S
Summary of Contents for Luxier BSH06-S
- Page 1 CA AB-1953 WaterSense CALGreen 7” 3.56” 5.56” 7.25” 2.3” 2.56” Max. Deck Thickness 2” 3” 1 3/8” Hole Size Approx. 24” water supply hose 3/8” compression tting *Drawing not to Scale. All Measurements are Approximate Luxier USA BSH06S Rev. A 02/2017...
- Page 2 (2) issue a refund of the purchase price paid for the product (Valid within 30 days from the date of purchase); or (3) issue a credit to be applied against the purchase of a new Luxier product. Shipping/delivery charges may apply and are in Luxier USA’s sole discretion.
- Page 3 • Use a mild detergent such as liquid dishwashing soap and warm water for cleaning. • Do not use abrasive / harsh chemical when cleaning the fi xture as they will damage and dull the fi nish. • When using spray cleaners, spray fi rst onto a soft cloth or sponge. Never spray directly onto the faucet as droplets can enter openings and gaps and cause damage. • After cleaning, rinse thoroughly with clean water to remove any cleaner residue. Luxier USA BSH06S Rev. A 02/2017...
- Page 4 1 minute to 12. O-ring clear any debris in the plumbing system. 13. Rubber Gasket Attach the aerator. 14. Metal Washer 15. Mounting Bolt 16. Locking Nut 17. Water Supply Hoses 18. Cap 19. Setscrew Luxier USA BSH06S Rev. A 02/2017...
