5.5"
2.3"
Luxier USA
Single Handle Kitchen Faucet with Pull Down Sprayer
Model Number:
KTS18-TB
KTS18-TC
KTS18-TO
15.5"
3.5"
2.4"
2.2"
3/8" Compression Fitting
1
Features:
- Brass and Zinc Alloy Construction
- Single Hole Installation
- Drip Free Ceramic Cartridge
- Maximum flow rate 1.8 gpm at 60 psi
- Pull Down 2 Stage Sprayer Head
- Complies with:
NSF 61-9
ANSI / ASME A112.18.1
CEC
IAPMO / UPC / cUPC
CSA B125-1
CA AB-1953
8.1"
1 1/2" Hole Size
Hose Length Approx. 20"
* Drawing not to scale. All Measurements are pproximate.
8.1"
Max. Deck Thickness 2"
KTS18 Rev.1 01/2018
Advertisement
Related Manuals for Luxier KTS18-TB
Summary of Contents for Luxier KTS18-TB
- Page 1 Single Handle Kitchen Faucet with Pull Down Sprayer Model Number: Features: - Brass and Zinc Alloy Construction KTS18-TB - Single Hole Installation KTS18-TC - Drip Free Ceramic Cartridge KTS18-TO - Maximum flow rate 1.8 gpm at 60 psi - Pull Down 2 Stage Sprayer Head...
- Page 2 (2) issue a refund of the purchase price paid for the product (Valid within 30 days from the date of purchase); or (3) issue a credit to be applied against the purchase of a new Luxier product. Shipping/delivery charges may apply and are in Luxier USA’s sole discretion.
- Page 3 • When using spray cleaners, spray fi rst onto a soft cloth or sponge. Never spray directly onto the faucet as droplets can enter openings and gaps and cause damage. • After cleaning, rinse thoroughly with clean water to remove any cleaner residue. KTS18 Rev.1 01/2018 Luxier USA...
- Page 4 1 minute and check 18. Steel Washer for leaks. Reattach the spray head. 19. Locking Nut 20. Screws (x2) 21. Water Inlet Tube 22. Rubber Washer 23. Counter Weight 24. Water Supply Hoses KTS18 Rev.1 01/2018 Luxier USA...
