Specifications
Warranty
2 years
Audio specifications
7.1 surround sound
Maximum distance
65 ft. (20m) (Up to 1080p)
Maximum resolution
3840 x 2160 (60Hz) at up to 22 ft. (7 m)
3840 x 2160 (30Hz) at up to 42 ft. (13 m)
1020 x 1080 (60 Hz) at up to 65 ft. (20 m)
Supported resolutions
3840 x 2160 (4K), 1920 x 1080, 1680 x 1050, 1600 x 900,
1440 x 900,
1360 x 768, 1280 x 800, 1280 x 768, 1280 × 720
Connector(s)
Input: 1 x DisplayPort (20 pin) Female
Output: 1 x DisplayPort (20 pin) Female
Indicators
1 x status LED
Environmental
Operating temperature: 0°C to 40°C (32°F to 104°F)
Storage temperature: -10°C to 60°C (14°F to 140°F)
Humidity: 0% ~ 80%
Instruction Manual
