Supported resolutions and cable lengths
Reference the table below for supported resolutions and cable lengths.
Cable length
from source
50 ft. (15 m)
26 ft. (8 m)
16 ft. (5 m)
Change your signal equalization
using Adjust controls
The DisplayPort booster features an equalization switch with ten different settings. You
can use the switch to adjust the amplification of your DisplayPort signal, to ensure that
your DisplayPort signal is ideal, at all distances up to 65 ft. (20 m).
If you're experiencing video issues, such as no display, a blinking display or other
imperfections after you've completed the installation steps, you can resolve these
issues by adjusting the signal amplification.
To adjust the signal amplification:
1. Press the + Adjust control button to cycle through positions above your current
setting.
2. Press the - Adjust control button to cycle through positions below your current
setting.
3. Reviewing your display at each position, and leave the switch in the position that
produces the best video performance.
Instruction Manual
Cable length to
display
15 ft. (5 m)
16 ft. (5 m)
6 ft. (2 m)
Total cable
length
65 ft. (20 m)
42 ft. (13 m)
22 ft. (7 m)
4
Maximum
resolution
1080p (60Hz) -
1920 x 1080
4K (30Hz) -
3840 x 2160
4K (60Hz) -
3840 x 2160
