Summary of Contents for StarTech.com DVIAEXT10
- Page 1 D V I EXTENDER Fiber Optic DVI Signal Extender DVIAEXT10 DVIAEXT20 DVIAEXT30 Instruction Guide DVIAEXT50 DVIAEXT70 DVIATEXT100 * Actual product may vary from photo The Professionals’ Source For Hard-to-Find Computer Parts...
- Page 2 FCC COMPLIANCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
-
Page 3: Table Of Contents
Table of Contents Introduction ............2 Connecting Your DVI Extender . -
Page 4: Introduction
Introduction Thank you for purchasing a StarTech.com DVI Extender. Using a unique integrated cable, you can operate your DVI display at up to 328 feet (100 meters) away from your computer system or other DVI signal source (depending on the model purchased) while maintaining excellent image quality. - Page 5 connection. The Remote Unit The Remote Unit connects to the video display using a conventional DVI cable, and sends the image sent over the integrated cable from the video source to the display. The Integrated Cable The Local Unit and Remote Unit are interconnected by a special integrated cable that performs two separate functions: •...
-
Page 6: Troubleshooting
Installing the Local Unit 1: Place the Local Unit near the computer or other video source. 2: Connect the Local Unit to the DVI output of the video source. Do not use any intermediate cable or adapter between the Local Unit and the computer. Installing the Remote Unit 1: Place the Remote Unit near the DVI display. -
Page 7: Specifications
Specifications Maximum Range 328 feet (100 meters) Integrated cable length varies by model Cable Characteristics Riser jacket of retardant PVC with 4 strands of H-PCF (Hard Polymer Clad Fiber) with a dimension of 200/225_m Tensile strength: 1800N Min. Bend Radius: 6” (15.4cm) Outside Diameter: 0.3”... -
Page 8: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 9 Revised: May 18, 2004...
