Installation and Operating instructions for
Control Cabinet PCs C63xx -0030
-0040
Version: 1.3
Date:
2011-02-21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C63 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Beckhoff C63 Series

  • Page 1 Installation and Operating instructions for Control Cabinet PCs C63xx -0030 -0040 Version: 1.3 Date: 2011-02-21...
  • Page 3: Table Of Contents

    Table of contents Table of contents General instructions Notes on the Documentation Liability Conditions Description of safety symbols Basic safety measures Operator's obligation to exercise diligence Operator requirements Product Description Appropriate Use Structure C6320, C6330 Structure C6325, C6335 Structure C6340, C6350 Interfaces USB interfaces Network connection...
  • Page 4 Table of contents Troubleshooting Fault correction Beckhoff Support & Service Beckhoff branches and partner companies Beckhoff Headquarters Beckhoff Support Beckhoff Service Assembly dimensions Appendix Technical data Approvals FCC: Federal Communications Commission Radio Frequency Interference Statement FCC: Canadian Notice C63xx...
  • Page 5: General Instructions

    © This documentation is copyrighted. Any reproduction or third party use of this publication, whether in whole or in part, without the written permission of Beckhoff Automation GmbH, is forbidden. Description of safety symbols The following safety symbols are used in this operating manual. They are intended to alert the reader to the associated safety instructions.
  • Page 6: Basic Safety Measures

    General instructions Basic safety measures Only switch the PC off after Before the Industrial PC is switched off, software that is running must closing the software be properly closed. Otherwise it is possible that data on the hard disk is lost. Please read the section on Switching the Industrial PC on and off.
  • Page 7: Operator's Obligation To Exercise Diligence

    General instructions Operator's obligation to exercise diligence The operator must ensure that • the Industrial PC is only used for its intended use (see also Product Description chapter). • the Industrial PC is in a sound condition and in working order during operation.
  • Page 8: Product Description

    Product Description Product Description Appropriate Use The C63xx series Industrial PCs in connection with a DVI / USB-Control- Panel CP68xx or CP78xx are designed for mounting in control cabinets for machine and plant engineering applications. The PCs of the series C63xx-0030 and C63xx-0040 differ in the configuration of the processor.
  • Page 9 Product Description View of the open PC C6330 The computer chassis can now be removed from the housing. The power supply is located in the lower part of the chassis (1), the 2,5” hard disk is located in the upper part (2). The slot motherboard (3) is located in the second slot of the housing.
  • Page 10: Structure C6325, C6335

    Product Description Structure C6325, C6335 Configuration without fan Example: Front view of the C6335 in basic configuration Opening the housing To open the PC housing, release the screw (1) by one turn using a screwdriver. The plastic cap (2) can be then be pulled forward, thereby releasing the lid (3).
  • Page 11 Product Description View of the open PC C6335 The computer chassis can now be removed from the housing. The power supply is located in the lower part of the chassis (1), the 2,5” hard disk is located in the upper part (2). The slot motherboard (3) is located in the second slot of the housing.
  • Page 12: Structure C6340, C6350

    Product Description Structure C6340, C6350 Configuration with 5 PCI-Slots Example: Front view of Industrial PC C6340 in basic configuration Opening the housing To open the PC housing, release the screw (1) by one turn using a screwdriver. The plastic cap (2) can be then be pulled forward, thereby releasing the lid (3).
  • Page 13 Product Description View of the open PC C6340 The computer chassis can now be removed from the housing. The power supply is located in the lower part of the chassis (1), the 2,5” hard disk is located in the upper part (2). The slot motherboard (3) is located in the second slot of the housing.
  • Page 14: Interfaces

    Product Description Interfaces Interfaces to the C63xx Industrial PCs USB interfaces USB1 – USB2 The two USB interfaces (1) and (2) are used for connecting the Control Panel CP68xx or CP78xx. USB2.0 standard is supported. Alternatively, peripheral devices with USB port may be connected. Network connection Network The PC is connected with the local network via the 10/100 Base-T RJ-45...
  • Page 15: Installation Instructions

    4. Please keep the associated paperwork. It contains important information for handling the unit. 5. Check the contents for visible shipping damage. 6. If you notice any shipping damage or inconsistencies between the contents and your order, you should notify Beckhoff Service. C63xx...
  • Page 16: Installation Of The Pc In The Control Cabinet

    Installation Instructions Installation of the PC in the control cabinet The C63xx Industrial PCs are designed for mounting in control cabinets for machine and plant engineering applications. The ambient conditions specified for operation must be observed (see chapter Technical data). Preparation of the control Four holes for the fixing bolts have to be provided in the control cabinet cabinet...
  • Page 17: Power Supply Connection

    Installation Instructions Power Supply Connection Supplied mains power unit The Industrial PC is fitted with a 24 V power supply unit . When the Industrial PC is provided with a power supply unit with integrated UPS (order option) you can realize an uninterruptible power supply (UPS) Note using the battery pack C9900-U330.
  • Page 18: Fitting The Cable

    Installation Instructions Fitting the cable Wiring in accordance with Fit the cables for the power supply of the Industrial PC, the connection of wiring diagram the battery pack as well as the connection of the power-switch in accordance with the wiring diagram, using the included material for assembling the connectors.
  • Page 19: Connecting Power Supply

    Installation Instructions Connecting Power Supply The external wiring consists of the connection of the power supply, the battery pack (optional) and the connection of customised components for shutting down the PC. Cable Cross Sections Note cable cross sections, For the connection of the power supply, wiring with a cable-cross-section avoid voltage drop! of 1,5 mm must be used.
  • Page 20: Wiring Diagram

    Installation Instructions Wiring diagram Wiring according to the wiring diagram (the circuit of PC_ON and Power- Status is symbolical): Wiring diagram power supply and external circuit The battery pack can only be connected when the Industrial PC is provided with an integrated UPS (order option). Note C63xx...
  • Page 21: Connecting Devices

    Installation Instructions Connecting devices The power supply plug must be withdrawn! Warning Please read the documentation for the external devices prior to connecting them. During thunderstorms, plug connector must neither be inserted nor removed. When disconnecting a plug connector, always handle it at the plug. Do not pull the cable! Connecting cables The connections are located at the top of the Industrial PC and are...
  • Page 22: Operating Instructions

    Operating Instructions Operating Instructions Please also refer to chapter General instructions. Switching the Industrial PC on and off The Industrial PC does not have its own mains switch. The Industrial PC Switch on will start when the equipment is switched on, or when it is connected to the power supply.
  • Page 23: Maintenance

    Operating Instructions Maintenance Please also refer to chapter General instructions. Cleaning the Industrial PC Switch off the Industrial PC and all connected devices, and disconnect the Industrial PC from the power supply. Danger The Industrial PC can be cleaned with a soft, damp cloth. Do not use any aggressive cleaning materials, thinners, scouring material or hard objects that could cause scratches.
  • Page 24: Ups Software Components (Optional)

    The driver software comes with a detailed help function. Beckhoff Information System The help files can be called up either directly from the configuration register by clicking the Help button, or under via Start > Programs > Beckhoff > UPS software components. C63xx...
  • Page 25: Troubleshooting

    Nothing happens after the Industrial No power supply to the Industrial Check power supply cable PC has been switched on Other cause Call Beckhoff Service The Industrial PC does not boot CD in the drive Remove CD and press any fully...
  • Page 26: Beckhoff Support & Service

    Please contact your Beckhoff branch office or partner company for local support and service on Beckhoff products! The contact addresses for your country can be found in the list of Beckhoff branches and partner companies: www.beckhoff.com You will also find further documentation for Beckhoff components there.
  • Page 27: Assembly Dimensions

    Assembly dimensions Assembly dimensions The following pages show diagrams of the Industrial PCs, with dimensions in mm. The assembly of the unit must take place with the orientation diagrammed here. Warning Industrial-PC C6320 Mounting plate at the rear panel front view side view Mounting plate at the side panel...
  • Page 28 Assembly dimensions The assembly of the unit must take place with the orientation diagrammed here. Warning Industrial-PC C6325 Mounting plate at the rear panel front view side view Mounting plate at the side panel side view front view C63xx...
  • Page 29 Assembly dimensions The assembly of the unit must take place with the orientation diagrammed here. Warning Industrial-PC C6330 Mounting plate at the rear panel front view side view Mounting plate at the side panel front view side view C63xx...
  • Page 30 Assembly dimensions The assembly of the unit must take place with the orientation diagrammed here. Warning Industrial-PC C6335 Mounting plate at the rear panel front view side view Mounting plate at the side panel side view front view C63xx...
  • Page 31 Assembly dimensions The assembly of the unit must take place with the orientation diagrammed here. Warning Industrial-PC C6340 Mounting plate at the rear panel front view side view Mounting plate at the side panel front view side view C63xx...
  • Page 32 Assembly dimensions The assembly of the unit must take place with the orientation diagrammed here. Warning Industrial-PC C6350 Mounting plate at the rear panel front view side view Mounting plate at the side panel front view side view C63xx...
  • Page 33: Appendix

    Appendix Appendix Technical data Industrial-PC C6320 Dimensions (W x H x D): 93 x 196 x 226 mm (without mounting plate) Weight: 4,0 kg (basic configuration) Industrial-PC C6325 Dimensions (W x H x D): 133 x 196 x 226 mm (without mounting plate) Weight: 6,0 kg (basic configuration) Industrial-PC C6330...
  • Page 34: Approvals

    Appendix Approvals FCC: Federal Communications Commission Radio Frequency Interference Statement FCC Approval for USA This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
