Code Squelch - Icom IC-iV85 Instruction Manual

• PERSONAL CALLS
This display appears when you are called with your ID code
and the calling station's ID code is 123.
• GROUP CALLS
This display appears when you are called with the group
code, 888, and 888 has been programmed into code channel
C6.
Code channel
• ERROR INFORMATION
When the transceiver receives an incomplete code, "E" and
previously received code appear.
Previously received code.
During channel number indication (described on page 20)
To use these functions in channel number indication, the
pager/code squelch setting must be programmed with other
memory contents before selecting channel number indication.
"CP" and " " blink.
PAGER/CODE SQUELCH

■ Code squelch

When using code squelch you will only receive calls from sta-
tions which know your ID or group code. A 3-digit code is sent
each time [PTT] is pushed in order to open the receiving sta-
tion's code squelch prior to voice transmission.
q Set the operating frequency.
• Set the volume and squelch to the desired level as in normal op-
eration.
w Push [FUNC], then push [
• Rotate [VOL] to select "dtm.CS," if "dtm.PG" or "dtm.OF" ap-
pears.
e Select the desired transmit code channel:
➥ Push and hold [
](0) for 1 sec. to enter code selec-
OPT
tion mode.
➥ Rotate [VOL] (or push [Y Y ]/[Z Z ]) to select the desired
code channel.
➥ Push[✱
] (or [CLR]) to exit code selection mode and
ENT
return to previous mode.
• 100 MHz digit shows "C."
r Operate the transceiver in the normal way (push [PTT] to
transmit; release [PTT] to receive).
t To cancel the code squelch, push [FUNC] and [
then rotate [VOL] to select "dtm.OF."
• 100 MHz digit shows "1" when the function is cancelled.
10
