Keypad Transmission Format Option Number; Table 3: Keypad Transmission Format - Rosslare AYC-E/Q60 Series Instruction Manual

Reader Functionality
•
Only one keypad transmission format can be active at any one
time.
•
When using the keypad transmission format "1 to 8 keys BCD,
Clock & Data" (Option 8) an additional input is required to
specify the number of keys in the PIN code.
5.2.4

Keypad Transmission Format Option Number

See Table 3 to determine the Option Number for the Keypad
Transmission Format you wish to select.
Keypad Transmission Format
Single Key, Wiegand 6-Bit (Rosslare Format)
Single Key, Wiegand 6-Bit with Nibble + Parity Bits
Single Key, Wiegand 8-Bit, Nibbles Complemented
4 Keys Binary + Facility code, Wiegand 26-Bit
1 to 5 Keys + Facility code, Wiegand 26-Bit
6 Keys BCD and Parity Bits, Wiegand 26-Bit
Single Key, 3x4 Matrix Keypad
1 to 8 Keys BCD, Clock & Data Single Key
Single key, Wiegand 4-Bit
* Option 1 is the default factory setting.
More information on each of the different keypad transmission
formats is available in the following subsections.
AYC-E/Q60 Family Instruction Manual

Table 3: Keypad Transmission Format

Option Number
1*
2
3
4
5
6
7
8
9
25
