Technical Specifications

2. Technical Specifications
Specifications
Electrical Characteristics
Power Supply Type
Operating Voltage Range
Input current standby (12
VDC)
Input Current Max (16 VDC) 130 mA
LED Control Input
Tamper Output
Cable Distance to Host
Controller
Max Proximity Card Read
Range*
Proximity Card Modulation
Proximity Card
Compatibility
Card Transmit Format
(Reader)
Keypad Transmit Format
(Reader)
LED Indicators
Communication
* Measured using a Rosslare proximity card (AT-R14) or equivalent.
Range also depends on electrical environment and proximity to
metal.
AYC-E/Q60 Family Instruction Manual
AYC-E/Q60
Linear type – recommended
5–16 VDC (when used as a controller,
provided by the secured series intelligent
power supply)
110 mA
Dry contact N.O.
Open collector, active low, 32 mA max sink
current
Up to 500 ft (150 meters) using an 18AWG
cable
Rosslare PROX: E – 40 mm, Q – 45 mm
HID Prox: E – 40 mm, Q – 45 mm
Rosslare PROX/HID Prox at 125 KHz
Rosslare PROX/HID Prox cards
Rosslare PROX cards: Wiegand 26-bit, or
Clock & Data
HID cards: According to card type
Programmable PIN code formats
Two tri-colored LEDs
Data1/C1, Data0/C2–open collector, 5 V
termination
