QUICK START PROCEDURE
Table 1. DC2684A-B AUTO and 4PV# Jumper Settings
JUMPER SETTING
AUTO (JP1) LO
HI
4PV# (JP2) LO
HI
Table 2. DC2684A-B Auto Mode Maximum Delivered Power
Capabilities Jumper Settings
PM1 PM0 Max Port Power
(JP4) (JP3) (Single-Signature)
LO LO
LO HI
HI LO
HI HI 71.3W
4
OPERATION
Host Control Required
Autonomous
Port powered only when both
pairsets present a valid signature
Any pairset presenting a valid
signature is powered
Max Pairset Power
(Dual-Signature)
40W 13W
51W 25.5W
62W 25.5W
35.6W
Figure 3. DC2685B-KIT Connections
Table 3. DC2685B-KIT Power Supply Voltage Range per PSE Type
IEEE TYPE
Type 3
Type 4
Table 4. DC2685B-KIT Address Settings
SW3
AD3
LO
LO
HI
HI
Supply Voltage Range
51V to 57V
53V to 57V
ADDRESS
AD2
LO 20h
HI 24h
LO 28h
HI 2Ch
