- Page 1 1339HFJ Model Revision 2.1 Updated Aug 27, 2012 Technical Manual & Parts Lists Atlanta Attachment Company 362 Industrial Park Drive Lawrenceville, GA 30046 770-963-7369 • www.atlatt.com...
- Page 3 Attachment Company. In addition to any confidentiality and non-disclosure obligations that currently exist between you and Atlanta Attachment Company, your use of these materials serves as an acknowledgment of the confidential and proprietary nature of these materials and your duty not to make any unauthorized use or disclosure of these materials.
-
Page 4: Table Of Contents
Technical Manual & Parts Lists Contents Important Safety Instruction ........................1 Liability ..............................2 Safety Equipment on the Machines ......................3 Protective Eyewear ............................. 4 Important Notices............................5 Maintenance ..............................7 Repair ................................8 A Word to the End User..........................9 Safety Precautions ............................ - Page 5 Technical Manual & Parts Lists 552-48 Right Angle Guide Assembly ....................... 40 1338-PD Pneumatic Diagram ........................41 1338-WD Wiring Diagram ........................42...
-
Page 6: Important Safety Instruction
Technical Manual & Parts Lists Important Safety Instruction This part of the Instruction Material is provided for the safe use of your equipment. It contains important information to help work safely with the unit and describes the dangers inherent in machinery. Some of these dangers are obvious, while others are less evident. -
Page 7: Liability
Technical Manual & Parts Lists Liability The machine should only be operated when in perfect working order, with due regard for safety and the potential dangers, as well as in accordance with the Instruction Material. Faults and malfunctions capable of impairing safety should be remedied immediately. We cannot accept any liability for personal injury or property damage due to operator errors or non-compliance with the safety instructions contained in this booklet. -
Page 8: Safety Equipment On The Machines
Technical Manual & Parts Lists A Word to the Operator The greatest danger inherent in our machines: is that of fingers, hands or loose clothing being drawn into a machine by live, coasting or rotating tools or assemblies or of being cut by sharp tools or burned by hot elements. LWAYS BE CONSCIOUS OF THESE DANGERS Safety Equipment on the Machines All machines are delivered with safety equipment, which shall not be removed or... -
Page 9: Protective Eyewear
Technical Manual & Parts Lists Protective Eyewear Protective eyewear that has been tested by the local authorities should be worn whenever there is a possibility of loose or flying objects or particles such as when cleaning the machine with compressed air. Tools Always count the number of tools in your possession before starting work on the machine. -
Page 10: Important Notices
Technical Manual & Parts Lists Important Notices Reporting and Fighting Fires Read the instructions posted in the factory with regard to reporting fires and the emergency exits. Make sure you know exactly where the fire extinguishers and sprinkler systems are located and how they are operated. - Page 11 Technical Manual & Parts Lists - Kinetic energy - Note that some motors or spindles, for example, may continue to run or coast run on after being switched off. - Potential energy - Individual assemblies may need to be secured if necessary for repair work. Delivery of the Machine/Packaging Note any markings on the packaging, such as weights, lifting points and special information.
-
Page 12: Maintenance
Technical Manual & Parts Lists Protect against influences from the surroundings: no structure-borne vibrations, no grinding dust, or chemical vapors. Protect against unauthorized access. Ensure that the machine and accessories are set up in a stable position. Ensure easy access for operation and maintenance (Instruction Manual and layout diagram); also verify that the floor is strong enough to carry the weight of the machine. -
Page 13: Repair
Technical Manual & Parts Lists Repair Replacement Parts We cannot accept any liability whatsoever for damage due to the use of parts made by other manufacturers or due to unqualified repair or modification of the machine. Repair, Electrical The power supply must be switched off (master switch off) and secured so that it cannot be switched on again inadvertently before starting any work on live parts. -
Page 14: A Word To The End User
Technical Manual & Parts Lists A Word to the End User The end user has sole responsibility to enforce the use of safety procedures and guards on the machine. Any other safety devices or procedures due to local regulations should be should be retrofitted in accordance to these regulations and/or the EC Directive on the safety of machines. -
Page 15: Electrical & Pneumatic Specifications
Technical Manual & Parts Lists Electrical & Pneumatic Specifications Electrical: 220 VAC, 5amp, 50/60 Hz Single Phase Pneumatic: 70 PSI, 20 SCFM avg. (3/8” Airline). Set the regulator to 70 PSI. Pressure setting valves: Parameter Settings for Efka Controller (11338SFJ27-PAR1) Before Programming, Perform a Master Reset of Parameters (See Below) PARAMETER RANGE... -
Page 16: Machine Operation
Technical Manual & Parts Lists Machine Operation Threading the Sewing Head Refer to the illustration below for threading directions. Warning: To avoid injury, disconnect the power source before threading the machine, making adjustments or performing maintenance. Threading the Thread Lubricator When the needle cooler is used, pass the thread under the center finger. -
Page 17: Adjustments
Technical Manual & Parts Lists Adjustments The adjustments mentioned below will have already been made at the factory before the unit is shipped. These instructions are for reference only. Warning: To avoid injury, disconnect the power source before making adjustments Differential Feed Mechanism 1. -
Page 18: Adjusting The Timing Of Loopers And Needle Guard
Technical Manual & Parts Lists Adjusting the Timing of Loopers and Needle Guard The looper and needle guard are set according to the dimensions in the illustrations on the left at the factory. Adjustment will depend on the sewn products and thread being used. -
Page 19: Machine Maintenance
Technical Manual & Parts Lists Machine Maintenance Regularly scheduled maintenance of the model 1338 unit reduces possible problems and downtime. Proper care will also ensure a longer life and better performance of the machine. Perform the following procedures to properly maintain the machine. 1. -
Page 20: Electric Eye Sensor Adjustment
Technical Manual & Parts Lists Electric Eye Sensor Adjustment To adjust the sensor, first remove the clear plastic cover from the end of the sensor. There are two adjusting screws under the cover. One is labeled “GAIN” and is used to set the sensitivity of the sensor. -
Page 21: Assembly Drawings & Parts Lists
Company. In addition to any confidentiality and non-disclosure obligations that currently exist between you and Atlanta Attachment Company, your use of these materials serves as an acknowledgment of the confidential and proprietary nature of these materials and your duty not to make any unauthorized use or... - Page 22 Technical Manual & Parts Lists...
-
Page 23: 11339Hfj27 Cap/Flange Workstation
Technical Manual & Parts Lists 11339HFJ27 Cap/Flange Workstation AAC Drawing Number 192122B Rev 3 QTY PART # DESCRIPTION 1337A-160 Air Table Assy Page 22 1338-022 Border Tray 1338-2000 Edge Guide Assy Page 28 1338-3000 Flange Holder Assy Page 30 1338-5000A Roll Holder Assy Page 32 1338-6000... - Page 24 Technical Manual & Parts Lists...
-
Page 25: 11338Hsj27 Sew Head Assembly
Technical Manual & Parts Lists 11338HSJ27 Sew Head Assembly AAC Drawing Number 192979C Rev 0 QTY PART # DESCRIPTION 11200A Bumper 112J27-01 Footlift Mnt Brkt 112J27-02 Arm Extension WWL10 Lock Washer AAQME-5-8 Elbow Fitting WWFS10 Flat Washer SSSC98032 Screw, Socket Cap 1338-012 Thread Guide SN135X722... - Page 26 Technical Manual & Parts Lists...
-
Page 27: 1337A-160 Air Table Assembly
Technical Manual & Parts Lists 1337A-160 Air Table Assembly AAC Drawing Number 1337296 Rev 7 QTY PART # DESCRIPTION 1335-159 ACCESS COVER 1337135 BLOWER ASSY Page 31 1337A-0161 ANGLE, CORNER 1337A-0163 WELDMENT, LEG, TABLE 1337A-150 AIR TABLE ASSY K-235 CONNECTOR,ROMEX,1/2" MMFB4444 FOOT, RUBBER NNH1/2-13... - Page 28 Technical Manual & Parts Lists...
-
Page 29: 1338H-1000 Console Assembly
Technical Manual & Parts Lists 1338H-1000 Console Assembly AAC Drawing Number 9000105 Rev 2 QTY PART # DESCRIPTION 1278-6689B BRACKET, EYE MOUNT 1338-018 SPACER, HEAD 1338-1500 PNEUMATIC PANEL ASSY 1338 Page 26 1338-4000 ELECTRICAL COMPONENTS AR 1338-PD DIAGRAM,PNEUMATIC Page 41 AR 1338-WD DIAGRAM,WIRING Page 42... - Page 30 Technical Manual & Parts Lists...
-
Page 31: 1338-1500 Pneumatic Panel Assembly
Technical Manual & Parts Lists 1338-1500 Pneumatic Panel Assembly AAC Drawing Number 192047B Rev 1 QTY PART # DESCRIPTION 0411-071 Regulator Brkt 1338-024 Pneumatic Panel AA198-503 Air Guage AA198-5102 Regulator AA198-RP3 Regulator AAEVQZ2121 Valve AAQME-4-8 Quick Male Elbow AAQME-4-4 Quick Male Elbow AAQME-5-4 Quick Male Elbow AAQPP-07... - Page 32 Technical Manual & Parts Lists...
-
Page 33: 1338-2000 Edge Guide Assembly
Technical Manual & Parts Lists 1338-2000 Edge Guide Assembly AAC Drawing Number 192042B Rev 3 QTY PART # DESCRIPTION 1278-6690 Nut Plate 1278-6942 Rod, Eye Mount 12787-1620 Standoff, Pivot 12787-1632 Standoff 12787-1634 Standoff, 2.5L 132556-511 Motor Mount 132556-513 Pivot Arm 1338-001 Mount Plate 1975-213... - Page 34 Technical Manual & Parts Lists...
-
Page 35: 1338-3000 Flange Holder Assembly
Technical Manual & Parts Lists 1338-3000 Flange Holder Assembly AAC Drawing Number 192043B Rev 0 QTY PART # DESCRIPTION 1335-320C Rod, 3/8 x 9 1335-816 Rod, 1/2 x 13.31 1338-008 Frame, Roll Holder 1338-027 Sensor Brkt 1338-028 Ring, Tape Guide 13453385 Scissor Holder 787-4A-032... -
Page 36: 1337135 Blower Assembly
Technical Manual & Parts Lists 1337135 Blower Assembly AAC Drawing Number 1337135 Rev2 NO. QTY PART # DESCRIPTION NO. QTY PART # DESCRIPTION 1337116 ADAPTOR, BLOWER SSFS98048 #10-32 X 3/4, FLAT SLOT 1337133 SPACER, BLOWER ASSY SSMBK13 KNOB,BLACK PLASTIC 1337134 GRILL,BLOWER INLET SSSC90016 #8-32 X 1/4 SOC CAP SC... -
Page 37: 1338-5000A Tape Roll Holder Assembly
Technical Manual & Parts Lists 1338-5000A Tape Roll Holder Assembly AAC Drawing Number 192119A Rev 1 QTY PART # DESCRIPTION 1335-816 Rod, S/S, 13.31l 1338-025C Tube, Roll Holder A-4-032 MM132-1496 End Cap SSSC01128 Screw, Socket Cap WWFE016 Fender Washer WWL1/4 Lock Washer WWSQ044 Square Washer... - Page 38 Technical Manual & Parts Lists...
-
Page 39: 1338-6000 Sewing Head Assembly
Technical Manual & Parts Lists 1338-6000 Sewing Head Mount Assembly AAC Drawing Number 192778C Rev 4 QTY PART # DESCRIPTION 11338HSJ27 Sew Head Assy Page 20 1338-030 Motor Cover SSBC98024 Screw, Button Cap 1338-003 Mount Plate 1338-004 Rod, 1/2 x 9 1338-005 Plate, Roller Mount WWL1/4... - Page 40 Technical Manual & Parts Lists...
-
Page 41: 1338-7000A Flange Guide Assembly
Technical Manual & Parts Lists 1338-7000A Flange Guide Assembly AAC Drawing Number 192124B Rev 1 QTY PART # DESCRIPTION 1335-345 Rod Link 1338-002 Mount Brkt 1338-006 Spacer 1338-007 Mount Block 1338-013 Shock Absorber Mount 1338-014 Cylinder Mount Brkt 552-48 Right Angle Guide Page 40 AA198RA508 Flow Control... - Page 42 Technical Manual & Parts Lists...
-
Page 43: 1339-100 Pneumatic Binder Assembly
Technical Manual & Parts Lists 1339-100 Pneumatic Binder Assembly AAC Drawing Number 192046B Rev 4 NO. QTY PART # DESCRIPTION NO. QTY PART # DESCRIPTION 1339-101 Main Mount SSPS98032 Screw, Pan Head 1339-102 Plate, Binder Mount SSSC98024 Screw, Socket Cap 1339-103 Side Block SSSC98032... - Page 44 Technical Manual & Parts Lists...
- Page 45 Technical Manual & Parts Lists 552-48 Right Angle Guide Assembly AAC Drawing Number 192123B Rev 0 QTY PART # DESCRIPTION F552-501A Left Top Plate F552-401B Right Top Plate F552-502 Middle Plate F552-503 Bottom Plate F552-404A Spacer F552-404B Spacer F552-404D Spacer F552-404E Nut Plate F552-404F...
- Page 46 Technical Manual & Parts Lists 1338-PD Pneumatic Diagram 125530B...
- Page 47 Technical Manual & Parts Lists 1338-WD Wiring Diagram 125531B...
- Page 48 Atlanta Attachment Company (AAC) Statement of Warranty Manufactured Products Atlanta Attachment Company warrants manufactured products to be free from defects in material and workmanship for a period of eight hundred (800) hours of operation or one hundred (100) days whichever comes first. Atlanta Attachment Company warrants all electrical components of the Serial Bus System to be free from defects in material or workmanship for a period of thirty six (36) months.
- Page 49 Declaración de Garantia Productos Manufacturados Atlanta Attachment Company garantiza que los productos de fabricación son libres de defectos de mate-rial y de mano de obra durante un periodo de ochocientos (800) horas de operación o cien (100) días cual llegue primero.
- Page 50 Atlanta Attachment Company 362 Industrial Park Drive Lawrenceville, GA 30046 770-963-7369 www.atlatt.com Printed in the USA...
