Welcome to use this real time car GPS tracker CCTR-803G.This product is with GPS module and 2G
GSM / 3G WCDMA module (with LBS locate without GPS), that has many new and unique functions, such as
built in rechargeable battery for power down alarm & tracker removed alarm, external microphone for listen
sound in car, remote turn off car engine,SOS button, playing back history tracking on website or mobile phone,
SMS locate with Google map link, sensitive shock sensor built in to control power saving etc. the tracker can
auto configure APN & GPRS setting, it is very easy to install and use, just connect the power supply is OK, the
working voltage range is 7-36V, it can be used for car (12V) or tuck (24V) bus etc.
The tracker sends the present location information through GPRS to internet server, so that user visit the
website
www.999gps.net
the ID, password is same with user name or is 123456, for example ID is 803201712345678, user name is
2345678, password is 2345678 or 123456) through any PC or mobile phone with available internet, current
location checking, history tracking playing back, alarm & running report etc can be operated, normally the
platform service charge is free (some distributor maybe sale different package of 1 year service charge free),
please confirm expired date after login the website, and the tracker will be active after the tracker power on.
User also can download Android or iPhone iOS app software to android or iPhone mobile phone, click the
app, logon with user name and password, you can locate current location & display history tracking, the user
name and password is same with the website login. Basically using mobile phone send SMS or call the tracker
can get the SMS of the current location Google map link.
This GPS tracker can be used as car alarm, fleet management, driver management etc, it can be used for
tracking cars, company vehicles, buses, taxis, trucks, etc.
CCTR-803G 3G Car GPS Tracker
with the applied user's name and password (default user name is the last 7 digital of
QR-Manual Download (Word)
iPhone App Download
QR-Manual Download (Pdf)
Android App Download
-1-
-201703
Advertisement
Table of Contents
Related Manuals for Carscop CCTR-803G
Summary of Contents for Carscop CCTR-803G
- Page 1 CCTR-803G 3G Car GPS Tracker -201703 Welcome to use this real time car GPS tracker CCTR-803G.This product is with GPS module and 2G GSM / 3G WCDMA module (with LBS locate without GPS), that has many new and unique functions, such as built in rechargeable battery for power down alarm &...
-
Page 2: Before Using
Product CCTR-803G SIM Card Holder ON/OFF Wires Switch Indicator Microphone SOS Button Socket Microphone Before Using Power ON / OFF Open SIM card room cover ,wave the switch in the direction of the arrow , the tracker will power on, if the tracker battery is low, the power &... - Page 3 : can not upload tracking Power supply For CCTR-803G, the tracker uses the 7-36V DC power supply, too high voltage or AC voltage may damage the tracker or even cause accidents, it is necessary connecting to car battery all the time, after the...
- Page 4 place that driver can press the button, connect one wire of the SOS button to GND (car body), another wire of the SOS button to the tracker SOS wire is OK. Microphone Installation Hole The external microphone need insert to the socket beside the wires on the case, and install the microphone in hidden place near the driver so that the tracker can have clear voice For car security the tracker need be installed in hidden place, normally the back of the seat or arm rest box or under the back window or room on the panel etc.
- Page 5 2. Connect the tracker power wire to the car battery and switch the ON/OFF to on position, the Green LED will be on continuously, the tracker is powered on, put the tracker outdoor for easy get GPS & mobile phone network signal. 3.
- Page 6 send back the information ”Add Preset Phone OK”, if the password is not right, the operation is fault, the tracker will send back information “Wrong Password”. Delete authorized phone number by SMS Send SMS “DELETEPHONE*123456*A” to the tracker, “DELETEPHONE” is a command; “123456” is password;...
- Page 7 password. Having successfully been made, there will be a reply sms to indicate the alarm will be noticed by sending a sms. Send SMS “SMSOFF*123456” to tracker, in which, “SMSOFF” is the fixed command and “123456”is the password. Having successfully been made, there will be a reply sms to indicate the alarm will not be noticed by sending a sms.
- Page 8 will make the total mileage to more error. 8. Start / Stop upload location to server The upload location to server function can be started or stopped by user, send SMS START*123456” or “STOP*123456” to tracker, “START” or “STOP” are command, “123456” is password. The tracker will send back information “Start / Stop upload location”, if the password is not right, the operation is fault, the tracker will send back information “Wrong Password”.
- Page 9 server IP is changed, we will notice on the website. 11. Check Tracker Current Setting Send SMS “CHECK*123456” to tracker, “CHECK” is the fixed command, “123456” is password. The tracker will send back information including software version, ID S/N number, IP address, authorized phone number, GPS and GSM signal etc.
-
Page 10: Locate Operation
The tracker will power off and then power on automatically, this will take a few minutes, and then cancel all the alarm setting in the tracker, including shock alarm, turn off car engine etc. 13. Back to factory configuration Send SMS “FACTORY*123456” to tracker, “FACTORY” is the fixed command, “123456” is password. The tracker will send back information “Set factory setting OK”, if the password is not right, the operation is fault, the tracker will send back information “Wrong Password”. - Page 11 If the tracker can not get the location in text description, it will reply the location with Google map link as follow. 3. Sending SMS to trigger report location by Google map link Send SMS “URL*123456” to the tracker, “URL” is a command, “123456” is password. If the operation is success, the tracker will send back the location information with Google map link to the sender.
- Page 12 “Wrong Password”. After go to shock alarm state, the system will check shock sensor, if the shock sensor is trigger (only continuously shock can trigger the shock alarm to avoid trigger by mistake), the tracker will send alarm and location information by SMS to the authorized phone number, and send the alarm information to the website server, also the tracker will call the authorized number A first, if no answered then B and C, if 3 authorized all no answered, then stop calling, If the tracker is triggered continually, every authorized phone will receive max 3 alarm SMS per hour.
- Page 13 SMS to the authorized phone number. If the tracker is triggered continually, every authorized phone will receive max 3 alarm SMS per hour. The over speed alarm SMS is as follow: Over Speed Alarm, current speed:XXX km/h After disable the over speed alarm, the system will not check speed again. Also send SMS “CANCELALARM*123456”...
- Page 14 listened. Hang up the calling will stop the LISTEN command. 11. Remote Turn Off Car Engine (Cut Oil Power) Send SMS “STOPENGINE*123456” to tracker, “STOPENGINE” is a command, “123456” is password, the car engine will be turned off immediately. The tracker will send back information “Turn Off Car Engine Success”, if the password is not right, the operation is fault, the tracker will send back information “Wrong Password”.
- Page 15 driver to confirm with the user is safe or not or call the police. Platform Operation Guide The platform operation please refer the platform operation guide, scan the following QR code or click the website link to download the platform manual, visit website www.999gps.net and click the Manual icon also can download the platform manual.
-
Page 16: Specification
After power on the tracker, the tracker GREEN LED keep on, and it has not any repose, and no ring, please confirm the SIM card has been installed properly, the SIM card PIN code is disable, and the SIM card has enough charge, and the mobile phone can work well in that place. -
Page 17: Packing List
GPS Hot Start Time 1 second average GPS Cold Start Time 36 seconds average Battery 300mAh (Polymer) Working Temperature C to +55 Absolute Working Temperature C to +80 Storage Temperature C to +80 Packing list: The main unit 1 pcs The user manual 1 pcs CD or Print... - Page 18 Customer Name Customer Phone SIM card Number Model CCTR-803G ID Number Purchase Date Expired Date Distributor Notes: The explanation of this manual is belonged to us, some small changes may not be noticed, if you have any problem please contact us, thanks!
