CCTR-809P Asset GPS Tracker User Manual
Welcome to use this asset GPS tracker. This product is with GPS module and GSM module, it use internal
high capacity battery, it is not necessary external power supply, it will weak up every day by setting time
interval(normally every day 1-2 times), it receive GPS Location (outdoor,10-20m precision) & LBS location
(indoor,50-500m precision) and upload the location to internet server, and then sleep automatically, user login
server with given user name & password can locate the tracker. If the tracker break the setting geo-fence, it will
send sms to notice owner, the working time can reach 3-5 years, it is water-proof with strong magnet, specially
suit for rent machine, vehicle, instrument, engineer sets tracking.
The proximity sensor built in will add the new function, like the remove alarm which will be triggered if the
unit is removed from its installation place.
The tracking website is
password, the last location will display on the map (the default given user name & password is the last 7 digital
of the tracker ID, the ID label is on the back of the tracker case), using Android App or iOS iPhone App also can
tracking the tracker, the user name & password is same with the website.
Scan the following QR code can download & install app on mobile phone.
Scan the following QR code or click the following link can download or read online the manual in Word or
Pdf format.
Word Version:
http://www.999gps.org/en/CCTR-809P-GPStracker-en-V1.doc
PDF Version:
http://www.999gps.org/en/CCTR-809P-GPStracker-en-V1.pdf
QR-Manual Download (Word)
www.999gps.net
, visiting this website & login with the given use name &
iPhone App Download
Android App Download
QR-Manual Download (Pdf)
-1-
---V1 201705
Advertisement
Table of Contents
Related Manuals for Carscop CCTR-809P
Summary of Contents for Carscop CCTR-809P
- Page 1 CCTR-809P Asset GPS Tracker User Manual ---V1 201705 Welcome to use this asset GPS tracker. This product is with GPS module and GSM module, it use internal high capacity battery, it is not necessary external power supply, it will weak up every day by setting time interval(normally every day 1-2 times), it receive GPS Location (outdoor,10-20m precision) &...
-
Page 2: Product Picture
Product Picture: Packing Manual Battery Screw Main Unit magnet Function Specification: 3-5 Years battery working time (1-2 location / Day); No installation,No power supply, Easy using; IP67 Water-proof, can be used in open air; 4 low self-consuming Li-battery (6000mAH); ... -
Page 3: Before Using
Before Using: 1. Install SIM card: Buy a GSM SIM card which have SMS service and incoming caller ID service & GPRS data service, in which the SIM card phone number is the very tracker number and all the operation for the tracker is to this number, such as locating immediately, add &... - Page 4 Note: This battery is not rechargeable battery, it can not be recharged. 4. Back to Factory Setting (Default Setting) Sending SMS “FACTORY*123456” to the tracker SIM card number, the tracker , the tracker will delete all the user setting (authorized number / Alarm setting / Password / APN / Working mode etc), reset to factory default setting, and then re-power on.
- Page 5 change the APN & GPRS manually, and send “CHECK*123456” to tracker can check the tracker setting, call the tracker SIM card supplier to confirm the APN & GPRS is right, please refer “Set APN & GPRS User name and Password” in the “Locate Operation &...
- Page 6 6. Set System Working Mode This Tracker has 3 working mode, mode 1 is timing on off (default factory mode), mode 2 is keep working, mode 3 is shock control. Sending SMS “MODE*123456*X*Y” to the tracker, “MODE” is command, “123456” is the tracker password, “X”...
- Page 7 The time interval default is 30 seconds, and it can be changed by sending SMS “INTERVAL*1234568*T” (T is from 030 to 999, unit is seconds). Under this working mode, the battery working time will reduce to only about 40 hours. Mode 3 ------ Shock Control ON/OFF SMS is : MODE*123456*3 Under this mode, the tracker normally is power off, if the tracker is triggered by shock sensor, the tracker...
- Page 8 the platform password for this user name also is :2345678,user can change the password after login. 10. Set APN & GPRS User name and Password This tracker can download & configure APN & GPRS username password automatically after power on, if the APN &...
- Page 9 CC830 :Protocol(CC800/CC828/CC830/CC630 etc) 800201512345678 :ID number 58.64.155.133,8011 :Server IP & Port :Upload Time Interval A:13987654321,B:13876543210,C:13765432101 :Authorized Number M1,24 :Working mode 1, 24 hours GPS 9 :GPS signal (Satellite) GPSON :GPS module is ON GSM:-95dBm :GSM signal CMNET :Current APN User :GPRS User Name Password :GPRS Password...
- Page 10 If the tracker can not get the location text description, the tracker will reply the location with Google map please refer the following 3. And If no GPS signal in that place the tracker will locate by link SMS to user, please refer the LBS (Cell ID GSM network base station), and reply the LBS location with Google map link.
- Page 11 about 50-500m, according to the around mobile phone base station density. The location SMS is like below, click the link the map is same with the above 2. No GPS signal, just LBS Cell ID Location http://maps.google.com/maps?q=40.756441,-73.986378 Battery:91% Note: The LBS location precision is not very high, in the city maybe 30-50 meters, in country side maybe over 300 meters according the GSM base station density.
- Page 12 The overspeed alarm SMS is as follow: Overspeed Alarm Current Speed:110km/h,Setting:100km/h Battery:88% Send SMS “OVERSPEEDALARMOFF*123456*” to the tracker will disable the over speed alarm setting, “OVERSPEEDALARMOFF” is command, “123456” is tracker password, the tracker will send back the information “Set Overspeed Alarm Off ” . Normally this function is used in working mode 2 &...
- Page 13 The move alarm SMS is as follow: Move Alarm https://maps.google.com/maps?q=22.67680,114.15188 Battery:88% 9. Remove Alarm The built-in proximity sensor will detect the unit work after it powers on. If it is removed from the installtion place with above 15 mm, this would trigger the remove alarm. Then it will send alarm sms to the authorized phone and tcp alrm message to the platform.
-
Page 14: Troubleshooting
Platform Operation The platform operation please refer the platform operation guide, scan the following QR code or click the website link to download the platform manual, visit website www.999gps.net and click the Manual icon also can download the platform manual. Platform User Guide Word Version Platform User Guide Word Version Trouble Shooting... -
Page 15: Packing List
Tracker SIM card Date Year month Model CCTR-809P ID Number Distributor Notes: The explanation of this manual is belonged to our company, some small changes may not notice customer, if you have any problem please contact us, thanks ! -15-...
