CCTR-820 Mini Water-proof GPS Tracker Using Guide
Welcome to use this Real Time mini water-proof GPS tracker CCTR-820, This product is with GPS
module and GSM module, It is specially design for motor , electric motor, engineer vehicle etc, it has very
wide working voltage (9-80V), it is water-proof, so it can work in the open air, it can upload current
location to website, display history tracking on website, also it has Google map link locate function
without platform, also it built in shock sensor to control power saving, shock & move alarm, over area
alarm, over speed alarm, etc.
User visit the website
through any computer with available internet, and without downloaded any software. And it can help to
arrange the whole fleet or the vehicles of company or group or personal vehicles with the anti-hijack
function.
And also user can download Android app software to android mobile phone, click the app, logon with
user name and password, you can locate current location & display history tracking, the user name and
password is same with the website login. Using mobile phone
locate current location, Send SMS or call the tracker, the tracker will send back the current location
Google map link by SMS.
This GPS tracker can be used as car alarm, fleet management, driver management etc, it can be
used for tracking cars, company vehicles, buses, taxis, trucks, moving equipments, transportations, etc.
iPhone App Download QR Code
Manual(Word) Download QR Code
www.999gps.net
with the applied user's name and password (Given by us)
visit
http://wap.999gps.net
Android App Download QR Code
Manual(Pdf) Download QR Code
also can

Advertisement

Table of Contents
loading

Related Manuals for Carscop CCTR-820

Summary of Contents for Carscop CCTR-820

  • Page 1 CCTR-820 Mini Water-proof GPS Tracker Using Guide Welcome to use this Real Time mini water-proof GPS tracker CCTR-820, This product is with GPS module and GSM module, It is specially design for motor , electric motor, engineer vehicle etc, it has very...

  • Page 2: Packing List

    GPS tracker Connect 9-80V Power RED: VCC (Battery + ) BLACK: GND or Car Body This Side face to sky Please don’t face to ground CCTR-820 Specification  Universal 4 GSM Band for Global; Wide Range Working Voltage: 9-80V DC; ...

  • Page 3: How To Install

    Note: 1. This tracker use 2G GSM network, and it upload tracking only through GPRS, it can not work in CDMA network or 3G(WCDMA or CDMA2000) network. (Some 3G SIM card can use in 2G GSM network, this kind of 3G SIM card can use in this tracker) 2.

  • Page 4: How To Use

    standby mode, the platform will display offline. RED---------- 9-80V battery + BALCK------ GND (Car Body) 2. Installation Place on the vehicle The tracker should be installed in the hidden place, then it is not easy to be broken and removed, because the GPS & GSM antenna are built in the tracker, so you should confirm the installation place have good GPS and GSM signal, the GPS antenna should face to sky, and it can not face to ground, please keep the tracker away from the big metal, we recommend install the tracker under the front panel of the car, or under the rear panel or under the rear glass, or in the pillar...
  • Page 5 3. After set the center number, park the car in the open place (indoor or underground can not receive the GPS signal), send SMS (Where# or 123#) to tracker with center number, the tracker will reply SMS with Google map link , click the link to visit internet, the map will display on your mobile phone.

  • Page 6: Command Instruction

    add or minus a fixed digit is your local time), you can change the display time to your local time by setting the time zone to your local time zone in the menu of My Account after logon the platform ( For example newyork time zone is -05), please refer the platform operation guide.
  • Page 7 Send SMS “alarm#” to the tracker will stop this alarming and back to arm state (stop make calling to center number, start detect shock sensor again,and car is still in alarm state), the tracker will reply stop alarm OK, but if the shock sensor is still trigger, the tracker will keep alarming. If the tracker has no reply, please check the tracker work properly and confirm the SMS command is right.
  • Page 8 sleep after stop moving can save battery power, and this can avoid the car battery run out, the tracker will reply set sleep time OK. If the tracker has no reply, please check the tracker work properly and confirm the SMS command is right. 9.

  • Page 9: Troubleshooting

    this SIM card, it is not necessary to input any password. Otherwise the tracker can not find GSM network, the Green LED will keep ON . This tracker use 2G GSM network, and it upload tracking only through 2G GPRS, it can not work in CDMA network or 3G(WCDMA or CDMA2000) network, if the 3G SIM card can use in 2G GSM network, then the SIM card can be used in this tracker.

  • Page 10: Warranty

    User Mobile Phone Tracker SIM card Date Year month Model CCTR-820 Serial Number Distributor Notes: The explanation of this manual is belonged to our company, some small changes may not notice customer, if you have any problem please contact us, thanks !
