CCTR-809A Animal GPS Tracker User Manual
Welcome to use this animal GPS tracker. This product is with GPS module and GSM module, it use
internal high capacity battery, it is not necessary external power supply, it will weak up every day by setting
time interval(normally every day 1-2 times), it receive GPS Location (outdoor,10-20m precision) & LBS location
(indoor,50-500m precision) and upload the location to internet server, and then sleep automatically, user login
server with given user name & password can locate the tracker. If the tracker break the setting geo-fence, it will
send sms to notice owner, the working time can reach 3-5 years, it is water-proof with strong magnet, specially
suit for rent machine, vehicle, instrument, engineer sets tracking.
The proximity sensor built in will add the new function, like the remove alarm which will be triggered if the
unit is removed from its installation place.
The tracking website is
password, the last location will display on the map (the default given user name & password is the last 7 digital
of the tracker ID, the ID label is on the back of the tracker case), using Android App or iOS iPhone App also can
tracking the tracker, the user name & password is same with the website.
Scan the following QR code can download & install app on mobile phone.
Scan the following QR code or click the following link can download or read online the manual in Word or
Pdf format.
Word Version:
http://www.999gps.org/en/CCTR-809A-GPStracker-en-V1.doc
PDF Version:
http://www.999gps.org/en/CCTR-809A-GPStracker-en-V1.pdf
QR-Manual Download (Word)
www.999gps.net
, visiting this website & login with the given use name &
iPhone App Download
Android App Download
QR-Manual Download (Pdf)
1
-
-
---V1 201706
Advertisement
Table of Contents
Related Manuals for Carscop CCTR-809A
Summary of Contents for Carscop CCTR-809A
- Page 1 CCTR-809A Animal GPS Tracker User Manual ---V1 201706 Welcome to use this animal GPS tracker. This product is with GPS module and GSM module, it use internal high capacity battery, it is not necessary external power supply, it will weak up every day by setting time interval(normally every day 1-2 times), it receive GPS Location (outdoor,10-20m precision) &...
-
Page 2: Product Picture
Product Picture: Packing Main Unit Manual Battery Optional accessories :Collar (L size for cattle,horse, M size for sheep ) M size L size Function Specification: 3-5 Years battery working time (1-2 location / Day); No installation,No power supply, Easy using; ... -
Page 3: Before Using
Remove alarm based on the high sensitive proximity sensor built in. Note: 1. The tracker will power on automatically after the battery is installed. 2. Please install GSM SIM card before install battery. 3. The SIM card need enable GPRS internet data service, every locating data cost is lower than 1K byte, every day 1-2 locating will cost 60K byte every month, the lowest data package is suit for suing. - Page 4 Please put this bottom side of the unit on a flat surface ! 2. Power ON / OFF When the battery is installed in the tracker(Please note all the battery in the battery holder are same direction, all the batteries are parallel connection, please see the “+” and “-” indicator in the battery holder), the tracker will power on automatically , the tracker will power on 5 minutes, and then go to sleep, after the setting time interval (default is 24 hours), the tracker will power on again and upload the location and sleep again, and...
- Page 5 2. Install the battery the tracker will power on, first time using please put the tracker outdoor for easy get GPS & GSM signal. 3. Check the LED flashing to confirm the tracker work well (Refer the above LED Flash Indicator).
- Page 6 Send SMS “CHECKPHONE*123456” or “400*123456” to the tracker number, “CHECKPHONE” & “400” are command; “123456” is password; the tracker will send back the information “Authorized Phone 13987654321； B：13876543210；C：13765432100 , the phone number is just an example. 3. Delete Authorized Phone Number by SMS Send SMS “DELETEPHONE*123456*A”...
- Page 7 means it work twice everyday. “YY” stands for the fixed time when the unit will start working, in 24 hours. “ZZ” stands for the local timezone. For example: “MODE*123456*1*24” means the unit will work once everyday, and it will start working at the time when it is powered on at the first time.
- Page 8 the interval time from 30 to 999, unit is seconds. The tracker will send back information “Set Interval time T OK”, if the password is not right, the operation is fault, the tracker will send back information “Wrong Password”. 30 seconds is the default interval time.
- Page 9 “123456” is the password of the tracker; “username” is the mobile company GPRS user name, “password” is the mobile company GPRS password, if the operation is success, the tracker will send back the information “Username:username, Password:password”, if the password is not right, the operation is fault, the tracker will send back information “Wrong Password”.
- Page 10 13. Re-power On & Reset Tracker Send SMS “RESET*123456” to the tracker number, “RESET” is a command, “123456” is password. The tracker will send back information “Reset Tracker and cancel all alarm setting”, then the tracker will power off and then power on automatically, and this command will not cancel user setting. 14.
- Page 11 operation is fault, the tracker will send back information “Wrong Password. The SMS examples is same as above. 3. Sending SMS trigger reply Google map link SMS(Platform is not necessary): Send SMS “URL*123456” to the tracker also can trigger the tracker locate & reply SMS with current location with Google map link, “URL”...
- Page 12 and location information by SMS to the authorized phone number, also the tracker will call the authorized number A first, if no answered then B and C, if 3 authorized all no answered, then stop calling, If the tracker is triggered continually, every authorized phone will receive max 3 alarm SMS per hour.
- Page 13 immediately, after located, the tracker will set current location as the geo-fence center and RRR as the geo-fence radius (unit is km), the tracker will send back the information “Geofence (A) Alarm On, RRRkm”, if the tracker can not locate, the tracker will reply “Can not locate, Set Geofence Alarm Fail”. After set the geo-fence alarm, the tracker will locate every 5 minutes to check the tracker is in the geo-fence circle or not (in working mode 1, only after the tracker weak up it will check the geo-fence alarm), if the tracker is out of the geo-fence circle, the tracker will send out geo-fence alarm information to all authorized...
-
Page 14: Troubleshooting
surface to avoid the mistake alarm. The actived lable must be removed before this function work well. 10. Check Alarm Setting Send SMS “ALARM*123456” to the tracker number, “ALARM” is command, “123456” is password, the tracker will send back the information of the alarm setting, for example: Shock Alarm:OFF,Move Alarm:OFF,Device removed Alarm:ON,Geo-Fence:OFF,OverSpeed:OFF,Power Down Alarm:ON,Alarm calling:ON,Alarm SMS:ON. -
Page 15: Packing List
This tracker use 2G GSM network, and it upload tracking only through 2G GPRS, some 3G & 4G card have 2G GSM network, this kind of SIM card can be used in this tracker. The tracking data on our server will keep 6-12 months, the old data will be deleted. After power on the tracker, call the tracker, no response, and no ring, please confirm the SIM card has been installed properly, and the SIM card has enough charge, and the mobile phone can work well in that place. -
Page 16: Warranty
User Mobile Phone Tracker SIM card Date Year month Model CCTR-809A ID Number Distributor Notes: The explanation of this manual is belonged to our company, some small changes may not notice customer, if you have any problem please contact us, thanks !
