Welcome to use this real time car GPS tracker CCTR-801B.This product is with GPS module and GSM
module, that has many new and unique functions, such as built in changeable & rechargeable battery (BL-5B)
for power down alarm & tracker removed alarm, built in microphone for listen sound in car, remote turn off car
engine,SOS button, playing back history tracking on website or mobile phone, SMS locate with google map,
sensitive shock sensor built in to control power saving etc. the tracker can auto configure APN & GPRS setting,
also user can send SMS to set the APN & GPRS. it is very easy to install and using, just connect the power
supply is OK, and it is wide working voltage range (9-36V), it can be used for car (12V) or tuck (24V) bus etc.
The tracker sends the present location information through GPRS to internet server, so that user visit the
website
www.999gps.net
last 7 digitals of the ID) through any PC or mobile phone with available internet, current location checking,
history tracking playing back, alarm & running report etc can be operated, normally the platform service charge
is free (some distributor maybe sale different package of 1 year service charge free), please confirm your
expired date after login the website, and the tracker will be active after the tracker power on.
User also can download Android or iPhone iOS app software to android or iPhone mobile phone, click the
app, logon with user name and password, you can locate current location & display history tracking, the user
name and password is same with the website login. Also following 999GPS official account on WeChat
software, map or text description location can be send back by WeChat. Basically using mobile phone send
SMS or call the tracker can get the SMS of the current location Google map link.
This GPS tracker can be used as car alarm, fleet management, driver management etc, it can be used for
tracking cars, company vehicles, buses, taxis, trucks, etc.
iPhone App Download
CCTR-801B Car GPS Tracker
with the applied user's name and password (default user name and password are the
QR-Manual Download (Word)
QR-Manual Download (Pdf)
Android App Download
-1-
-V3-20150601
Wechat Official Account
Advertisement
Table of Contents
Related Manuals for Carscop CCTR-801B
Summary of Contents for Carscop CCTR-801B
- Page 1 CCTR-801B Car GPS Tracker -V3-20150601 Welcome to use this real time car GPS tracker CCTR-801B.This product is with GPS module and GSM module, that has many new and unique functions, such as built in changeable & rechargeable battery (BL-5B) for power down alarm & tracker removed alarm, built in microphone for listen sound in car, remote turn off car engine,SOS button, playing back history tracking on website or mobile phone, SMS locate with google map, sensitive shock sensor built in to control power saving etc.
-
Page 2: Before Using
Product CCTR-801B Wires ON/OFF Button SOS Button Indicator Before Using Power ON / OFF If the tracker is powered OFF, connect the power wire to the car battery can make the tracker power on automatically, also press and hold the ON/OFF Button and release after the GREEN LED is ON, the tracker will power on. - Page 3 : can not upload tracking Power supply For CCTR-801B, the tracker uses the 9-36V DC power supply, too high voltage or AC voltage may damage the tracker or even cause accidents, it is necessary connecting to car battery all the time, after the...
- Page 4 The working temperature is -20℃ to 60℃, over this range the specification maybe can not reach the standard level. the storage temperature can reach to -40℃ to 80℃. Simply Using Step 1. First to buy a 2G GSM phone SIM card and enable GPRS service, order a data package 20-30M (Normally tracker will use 20M data every month), install in the tracker, please refer Before Using 2.
- Page 5 Add authorized phone number Send SMS“ADDPHONE*123456*A*number”(Not including the quotation marks “ ”, Number means the telephone number you want preset, the following is same) to tracker is OK, “ADDPHONE” is a command; “123456” is password; “A” is authorized number location, every tracker have 3 authorized phone number locations, A and B, and C, so you can set 3 phone numbers, if the add operation is success, the tracker will send back the information ”Add Preset Phone OK”, if the password is not right, the operation is fault, the...
- Page 6 alarm is triggered, the tracker will call the authorized number to notice the alarm, the default setting is ON. 4. Set Alarming Notice by Sending SMS: ON/OFF Send SMS “SMSON*123456” (Sending SMS to authorized number) or “SMSOFF*123456” (No SMS) to the tracker, “SMSON”...
- Page 7 trigger replying SMS with balance, then the sms is CXYE. Having successfully been made, there will be a SMS “Balance SMS: CXYE” . Notice: After finish the above setting, it is not necessary to set again unless the tracker SIM card company changed or the tracker setting is changed to factory, later every time just sending following SMS can trigger the tracker to check balance.
- Page 8 low and can not start car engine, we do not recommend this working mode. 8. Set Car Plate Name Send SMS “PLATE*123456*PlateName” to tracker, “PLATE” is a command, “123456” is password, “PlateName” is the car plate number or name, after setting the car plate, the reply to tracker SMS will add car plate to indicate which car reply this message.
- Page 9 change them manually, please confirm the auto configuration of APN & GPRS user name password is right, call your tracker SIM card mobile phone company to get the APN & GPRS setting, sending SMS “CHECK*123456” to the tracker can check the current APN & GPRS auto setting. if the APN & GPRS are not right, please set by the following description.
-
Page 10: Locate Operation
58.64.155.133,8011, ;Server IP & Port 13987654321, ;Authorized number (A/B/C) GPS OK , ;GPS status ShockControlGPS, ;GPS module shock control -95dBm, ;GSM signal strength ShockControlGPRS, ;GPRS is controlled by shock sensor CMNET, ;APN name User, ;GPRS user name Password, ;GPRS password 46000, ;Sim Card MCC+MNC e1d/24a0,... - Page 11 and locate immediately, a few seconds later, the tracker will send back the location information with text description by SMS to the caller. If the tracker has not authorized number, any phone calling can trigger the tracker to locate immediately, if the tracker has authorized number, then only authorized phone calling can trigger the tracker to locate immediately.
- Page 12 signal weak (underground park or indoor etc), the tracker will change to LBS locate (located by GSM network base station), and reply a location with Google map link to the caller or sender. User click the link, the location in google map will display like above, the SMS example is as follow: No GPS signal, Just Cell ID Location: http://maps.google.com/maps?q=N22.6775,E114.1518 Note: this location is locate by GSM base station ID, the precision is not very high, in the city maybe 30-50...
- Page 13 the tracker also can trigger the tracker to enter arm state. Shock alarm notice by sending SMS & calling can be enabled ON or OFF, please refer Tracker Setting Command 3 &4. 6. Set Over Speed Alarm by Sending SMS Send SMS “OVERSPEEDALARMON*123456*xxx”...
- Page 14 command. 10. Remote Turn Off Car Engine (Cut Oil Power) Send SMS “STOPENGINE*123456” to tracker, “STOPENGINE” is a command, “123456” is password, the car engine will be turned off immediately. The tracker will send back information “Turn Off Car Engine Success”, if the password is not right, the operation is fault, the tracker will send back information “Wrong Password”.
-
Page 15: Platform Operation
Platform Operation The platform operation please refer the platform operation guide, scan the following QR code or click the website link to download the platform manual, visit website www.999gps.net and click the Manual icon also can download the platform manual. Platform User Guide Word Version Platform User Guide Word Version Notes &... -
Page 16: Specification
The tracking data on our server will keep 6-12 months, the old data will be deleted. The tracker auto power off: please confirm the tracker power supply is well connected to car battery and the power fuse is well. After power on the tracker, the tracker GREEN LED keep on, and it has not any repose, and no ring, please confirm the SIM card has been installed properly, the SIM card PIN code is disable, and the SIM card has enough charge, and the mobile phone can work well in that place. -
Page 17: Packing List
Customer Name Customer Phone SIM card Number Model CCTR-801B ID Number Purchase Date Expired Date Distributor Notes: The explanation of this manual is belonged to our company, some small changes may not notice...
