Welcome to use this car GPS tracker CCTR-803BT with temperature detection.This product is with GPS
module (with A-GPS function for fast locating) GSM module (with LBS locate without GPS) & temperature
detection sensor, it has many new and unique functions, such as built in rechargeable battery for power down
alarm & tracker removed alarm, playing back history tracking on website or mobile phone, SMS locate with
Google map link, sensitive shock sensor built in to control power saving etc. the tracker can auto configure
APN & GPRS setting, it is very easy to install and use.
The tracker sends the present location information & temperature information through GPRS to internet
server, so that user visit the server with the applied user's name and password can track the vehicle, platform
operation please refer the manual of the tracking platform.
Product
CCTR-803BT
Temperature
Sensor Socket
Power Supply
Socket (+5V)
USB
Supply Wire(+5V)
CCTR-803BT Car GPS Tracker
QR-Manual Download (Word)
Power
QR-Manual Download (Pdf)
Temperature
Sensor(10 Meters)
-1-
-V1-20150911
SIM Card
Holder
LED
Indicator
Advertisement
Table of Contents
Related Manuals for Carscop CCTR-803BT
Summary of Contents for Carscop CCTR-803BT
- Page 1 CCTR-803BT Car GPS Tracker -V1-20150911 Welcome to use this car GPS tracker CCTR-803BT with temperature detection.This product is with GPS module (with A-GPS function for fast locating) GSM module (with LBS locate without GPS) & temperature detection sensor, it has many new and unique functions, such as built in rechargeable battery for power down alarm &...
-
Page 2: Before Using
Before Using Power ON / OFF If the tracker is powered OFF, turn the switch to the on position with slim stick, the tracker will power on, the LED will flash, please refer the following 3 for detail LED flash indicator. ON/OFF Switch If the tracker is powered ON, turn the switch to the off position with slim stick, the tracker will power off. - Page 3 : can not upload tracking Power supply For CCTR-803BT, the tracker uses the 5V DC power supply, too high voltage or AC voltage may damage the tracker or even cause accidents, it is necessary connecting to 5V power supply. Power Down Alarm: When the tracker power supply is off or the voltage is too low, the GREEN LED of the tracker will flash 3 times, and then the tracker will send power down alarm SMS to the authorized number.
- Page 4 signal well. And Red LED flash once means the location has been uploaded to the server. 4. Call the tracker or send SMS “LOCATE*123456” or “URL*123456” to the tracker, the tracker will reply the tracker location with text description or Google map link by SMS. 5.
- Page 5 The tracker password is used to protect the tracker only can be operated by owner, every SMS command need follow tracker password, the default tracker password is 123456, for higher security please change the tracker password. Change tracker password Send SMS “CHANGEPASSWORD*123456*888888” to tracker, “CHANGEPASSWORD” is a command; “123456”...
- Page 6 Having successfully been made, there will be a SMS “Balance Mode: SMS”. Send SMS “BALANCEMODE*123456*CALL” to the tracker, it means calling USSD command number to check balance, in which, “BALANCEMODE” is the fixed command, “123456” is the password and “CALL” means calling USSD number.
- Page 7 Password”. the default setting is Shock Control, when the tracker begin to move, the tracker begin upload the tracking, the tracker status on the platform will change to online immediately. if the tracker stop moving, the tracker will stop upload the tracking and turn off GPS & GPRS to go to sleep mode , a few minutes later the tracker status on the platform also will change to offline.
- Page 8 10. Start / Stop upload location to server The upload location to server function can be started or stopped by user, send SMS START*123456” or “STOP*123456” to tracker, “START” or “STOP” are command, “123456” is password. The tracker will send back information “Start / Stop upload location”, if the password is not right, the operation is fault, the tracker will send back information “Wrong Password”.
- Page 9 13. Check Tracker Current Setting Send SMS “CHECK*123456” to tracker, “CHECK” is the fixed command, “123456” is password. The tracker will send back information including software version, ID S/N number, IP address, authorized phone number, GPS and GSM signal etc. if the password is not right, the operation is fault, the tracker will send back information “Wrong Password”.
-
Page 10: Locate Operation
tracker will send back information “Set factory setting OK”, if the password is not right, the operation is fault, the tracker will send back information “Wrong Password”. After this, The tracker will cancel all the alarm setting in the tracker, including shock alarm, move alarm, geo-fence alarm, over speed alarm, delete all the authorized phone number, delete the APN and GPRS user name and password,change the tracker password to 123456, reset the IP address, reset the system working mode and the interval time, and so on. - Page 11 success, the tracker will send back the location information with Google map link to the sender. User click the link, the location in google map will display, the SMS example is as follow: https://maps.google.com/maps?q=22.67680N,114.15188E Battery:88% 4. LBS Locate with Google map link without GPS signal After sending SMS or calling the tracker to trigger locate, if the tracker can not receive GPS signal or GPS signal weak (underground park or indoor etc), the tracker will change to LBS locate (located by GSM network base station), and reply a location with Google map link to the caller or sender.
- Page 12 receive max 3 alarm SMS per hour. If the authorized number have been set, use the authorized phone number to send SMS “ARM#” to the tracker also can trigger the tracker to enter arm state. The shock alarm SMS is as follow: Shock Alarm https://maps.google.com/maps?q=40.756441N,73.986378W Send SMS “SHOCKALARMOFF*123456”...
- Page 13 Send SMS “ALARM*123456” to tracker, “ALARM” is a command, “123456” is password, the tracker will send back the information “Shock Alarm:OFF, Over Speed Alarm:OFF,Power Down Alarm:ON,Alarm calling:ON,Alarm SMS:ON” to indicate all the alarm setting, if the password is not right, the operation is fault, the tracker will send back information “Wrong Password”.This command is used for check the tracker alarm setting.
-
Page 14: Specification
The tracker auto power off: please confirm the tracker power supply is well connected to car battery and the power fuse is well. After power on the tracker, the tracker GREEN LED keep on, and it has not any repose, and no ring, please confirm the SIM card has been installed properly, the SIM card PIN code is disable, and the SIM card has enough charge, and the mobile phone can work well in that place. -
Page 15: Packing List
Customer Name Customer Phone SIM card Number Model CCTR-803BT ID Number Purchase Date Expired Date Distributor Notes: The explanation of this manual is belonged to our company, some small changes may not notice...
