Compatible spa controllers: in�xm2, in�xe, in�yt, in�yj and in�ye with compatible software revision� Aeware®, Gecko®, and their respective logos are Registered Trademarks of Gecko Alliance Group� in�k1000™, in�xm2™, in�xe™, in�yt™, in�ye™, in�yj™, in�tune™, in�stream™, in�stream 2, in�mix™, in�clear™, in�touch™ and in�therm™, and their respective logos are trademarks of Gecko Alliance Group�...
Fun, simple, engaging one level menu interface Parting ways with physical buttons, keys and overlays, Gecko’s in�k1000 touchscreen keypad is fun to use, simple to learn and features an intuitive and engaging one level menu interface�...
Installation Installation of in.k1000 When installing the keypad on the spa, a minimum angle of 4 degrees must be respected� 4° To install the in�k1000, use the drilling template provided in this section� Determine the mounting location and stick the template on the chosen location�...
The in�k1000 must be installed on the outside edge of the hot tub, so that it is not subject to moisture trapped by the cover� Connecting in.k1000 to the spa pack Main keypad in�k1000 To connect the in�k1000 keypad, simply insert its in�link connector into the appropriate keypad connector of the pack enclosure (as illustrated)�...
Page 10
Installation Installation errors Upon connecting the in�k1000 to the spa pack you may see one of two error messages� Please follow the instructions in the message or contact your dealer for more information�...
Keypad functions in.k1000 keypad layout direct to function selection wheel (settings and all-on or all-off key additional options) (one touch activation) mode selection wheel (settings and on-screen accessories) system messages and reminders interactive display icons (main spa functions) Power Touch the screen to turn on the keypad� 3 minutes after the last pump is turned off, the screen will shut off if there is no touch activity�...
Keypad functions Start or stop accessories To start or stop an accessory, touch the associated icon� Icons will become animated when their accessory is turned on, and animation will stop when turned off� Icons on the screen will reflect the speed or state of the devices running on your spa�...
Keypad functions Water temperature The temperature shown at the bottom of the screen shows the current water temperature� Use the Up and Down icon to set the desired temperature� The set point will appear in blue� After 3 seconds without any change to the set temperature value, the current water temperature will reappear�...
Keypad functions Contrast page Use this page to change the display contrast� Settings In the Settings page you can access the following: • WaterCare • Maintenance • Date & Time • Keypad • Electrical Config • Wi-Fi • About To select an item, slide the right wheel until the desired icon is highlighted in the middle or press on the menu name�...
Keypad functions Water care The Water Care page will help you set up your ideal filtration and heating settings� Choose between Away from Home, Beginner, Energy Savings, Super Energy and Weekender, depending on your need� Touch the Water care name to choose your setting� A green checkmark will appear on the selected icon to confirm your choice �...
Keypad functions Modifying schedules To modify a Water Care category, touch the pen icon at the right end of the desired watercare to open the selected Water Care menu� Touch the Economy tab to change the economy setting and filter cycle tab for the filtration settings (or schedules)� You can add economy or filtration schedules by touching the «...
Keypad functions Date and time Simply touch the item you want to change� Set date Here you can adjust the year, month and day� Simply swipe up and down the column you want to change, and select the desired value� When done, touch the calendar icon at the right of the screen�...
Keypad settings Here you can adjust the Temperature Units, Day/Night contrast, and Display orientation and language� Simply touch the item you want to change� Temperature units Choose the appropriate units to display temperatures� Display page Use this page to change the display orientation�...
Keypad functions Contrast page Simply touch the item you want to change� Language Select Use this page to select the display language of the in�k1000 keypad� Electrical configuration Please do not make changes in this section unless you are a qualified electrician. In this section you can change the low-level configuration, as well as modify the number of phases and the input current�...
Keypad functions Wi-Fi This menu is present if the in�touch module is present� This page allows you to connect your in�touch module to a Wi-Fi network or to change its network� For more details about other in�touch connection methods please see the in�touch techbook� After a few seconds the available networks will appear on the screen, as well as their signal strength�...
Keypad functions Wipe screen This message appears when too much water is detected on the touch screen� Simply wipe away excess water� in.stream 2 functions This menu is available only if the in�stream 2 audio station is detected in the spa accessories� The audio page will allow you to control the active audio source�...
Keypad functions Speakers Settings Move the sliders to adjust the Balance, Fader and subwoofer settings� The Fader and Subwoofer sliders will only appear in the Speaker menu if the corresponding speakers are installed on the in�stream 2� Source Menu To change the audio source, simply tap on the desired one� Note that only the sources installed on the in�stream 2 will be displayed in the source menu�...
Page 23
Keypad functions in.clear on/off Use the On/Off submenu to turn on or off the in�clear sanitation system� Bromicharge level ™ The Bromicharge page allows you to see the current level of sodium bromide in the water� Ideally, you should aim to be near the center of the green area of the gauge�...
Error messages The list below shows the different error messages that can appear on the home screen� Refer to the troubleshooting and error codes section of the TechBook for your spa pack system� Please note that if you are in a swim spa configuration, the message may be followed by "Master" or "Slave" to designate from which pack the error is coming from�...
Feature matrix The following table presents the features and/or options available for the in�k1000 keypad, and the earliest software version at which this feature/option is available� All versions greater than the earliest version continue to support the feature� Keypad functions Earliest support Power 5�00...
Specifications Part number 0607-005024 Model IN�K1000-BK-GE1 Environmental Operating temperature: -4°F (-20°C) to 149°F (65°C) Storage temperature: -22°F (-30°C) to 185°F (85°C) Water ingress protection: IPX5 Mechanical Weight: 1�05 lbs (0�48 kg) Dimensions (W x H x D): 7,49" x 5,17" x 1,93" (190 mm x 1031 mm x 49 mm) Audio specifications Audio source supported:...
