- Page 1 TechBook in.mix 300 LED controller & power supply a lighting control console at your fingertips up to 3 different color zones the power to illuminate...
-
Page 2: Table Of Contents
Table of contents Safety instructions 2 Warnings 3 Introduction 5 Overview 6 Dimensions 7 Installation 8 Connections - Preparation 9 - Compatible LED lights 11 - Other compatible LED lights 12 - Other connections 14 Compatible keypads 15 Troubleshooting 16... -
Page 3: Safety Instructions
, and their respective logos are Registered Trademarks of Gecko Alliance Group ® ® inmix 300™, instream 2™, ink1000™, ink800™, ink500™ and their respective logos are Trademarks of Gecko Alliance Group All other product or company names that may be mentioned in this publication are tradenames, trademarks or registered trademarks... -
Page 4: Warnings
* "CAUTION – RISK OF ELECTRIC SHOCK REPLACE COMPONENTS ONLY WITH IDENTICAL COMPONENTS"; * WARNING – TO PREVENT DAMAGE, FIRE AND ELECTOCUTION DO NOT CONNECT LIGHT ASSEMBLY CABLE THAT HAS NOT BEEN APPROVED BY GECKO * DO NOT SERVICE THIS PRODUCT YOURSELF AS OPENING OR REMOVING COVERS MAY EXPOSE YOU TO DANGEROUS VOLTAGE OR OTHER RISK OF INJURY REFER ALL SERVICING TO QUALIFIED SERVICE PERSONNEL * WHEN THE POWER SUPPLY CONNECTIONS OR POWER SUPPLY CORD(S) ARE DAMAGED;... -
Page 6: Introduction
Introduction inmix 300 LED controller & power supply for your spa The inmix 300 provides the low voltage required to power the RGB LED fixture of your spa When connected to one of our X or Y series control systems for spas and hot tubs, inmix transforms our ink1000 touch screen and ink800 color display keypads in real lighting consoles with a perfect interface Create your personalized ambiance easily with an infinite... -
Page 7: Overview
Overview CO port OUT 1 OUT 4 OUT 2 OUT 3 The inmix 300 module supports 3 LED zones Zone 1 supports 2 types of connexions (A and B) The type A connection is made for 5 pin LEDs and the type B connection is for 4 pin LEDs (see page 9 for the pin functions) It is important to note that these 2 connections will always output the same color, since they are in the same Zone 1 All zones may be used at the same time, but the total permissible power should always be respected... -
Page 8: Dimensions
Dimensions 703" 222" (179 mm) (56 mm) 638" (162 mm) Front view Side view... -
Page 9: Installation
Installation To prevent water from getting inside the device, the inmix 300 should be installed on a vertical surface as shown below: 4" (100 mm) Secure the in.mix 300 The following material is recommended: Firmly attach upper mounting holes one at a time on each 2 - # 10 screws of appropriate length with round, side of the apparatus truss or pan head... -
Page 10: Connections
Connections Preparation To prevent electric shock hazard, do not connect to main power supply while the cover is removed. Gasket Remove the cover screws from the front of the apparatus with a Phillips screw driver Before closing, please make sure the in.mix 300 gasket is well in place. Remove all seals and insert LED wire Repeat for every LED lights you need to connect The inmix 300 powers the LEDs with DC current** controlled independently through switching The current... - Page 11 Connections Connection for the 5VDC Output version: The inmix 300 is compatible with Molex’s SL series LED connectors Female Housing 4 Pos : #50-57-9404 Female Housing 5 Pos : #50-57-9405 Pin Female part number (AWG 22-24) : #16-02-0102 ** The output voltage is switched to simulate the power of a inmix 300 - 5 volts 5V output.
-
Page 12: Compatible Led Lights
Connections Compatible LED lights Contact Gecko Alliance to determine if the LED models you plan on using are compatible If J&J Electronics Inc’s Spyder LEDs from their ColorCHOICE™ series are used, a maximum of 100 are supported by the inmix-300 They may be distributed in any way through the 3 Zones The Out 1 is compatible with the J&J cluster... -
Page 13: Other Compatible Led Lights
Connections Other compatible LED lights Rosstech MTA-100 FEMALE 4 POSITIONS TYCO P/N: 3-640440-4 Function Maximum LED Quantity: 100 LEDS 1 (red) BLUE Consumption: 12V 2 (green) GREEN 3 (white) 4 (black) Rising Dragon MOLEX P/N : 16-02-0102 4X MOLEX P/N: 50-57-9404 Function Maximum LED Quantity: 120 LEDS 1 (blue) - Page 14 Connections Other compatible LED lights Sloan LED MTA-100 FEMALE 4 POSITIONS TYCO P/N: 3-640440-4 Function Maximum LED Quantity: 120 LEDS 1 (black) BLUE Consumption: 12V 2 (white) GREEN 3 (green) 4 (red) Proway MOLEX P/N : 16-02-0102 4X MOLEX P/N: 50-57-9404 Function Maximum LED Quantity: 120 LEDS 1 (blue)
-
Page 15: Other Connections
Connections Other connections Complete the cabling as follows: CO on the enclosure to connect to other accessories To CO Pack AC Power input Connect the CO cable of the inmix 300 to the CO Connect the AC power cable of the inmix 300 to a direct connector of the spa pack See the documentation output of the spa pack See the documentation related related to your specific pack model for more details on... -
Page 16: Compatible Keypads
Compatible keypads List of keypads compatible with in.mix 300 For more information on the keypads compatible with your inmix 300 refer to the corresponding techbook ink800 main keypad ink1000 main keypad Color LCD display, 10 keys Color LCD capacitive touchscreen display... -
Page 17: Troubleshooting
Troubleshooting Led Diag #2 Led Diag #1 LED Diagnostic #1 This LED is normally always lit (red) If it is not lit, this indicates a short circuit (or an overload) on the V power supply This unit supplies a maximum of 16A •... -
Page 18: Specifications
Specifications Alim Alim Model number Description Molex MTA100 J&J 4 pos in.link 0609-521001 inmix 300-SL-AMP-V-GE1 • • • 0609-521002 inmix 300-SL-IN-5V-GE1 • • • 0609-521003 inmix 300-MTA-AMP-12V-GE1 • • • 0609-521004 inmix 300-MTA-IN-12V-GE1 • • • 0609-521005 inmix 300-JJ-IN-5V-GE1 • •... - Page 19 Specifications European certifications EN/IEC60335-1: 2010/A1: 2013 EN/IEC60335-2: 60/A2: 2008 CSA No 222 - 2181 - M89 CEM Europe EN 55014-1 EN 55014-2 EN 61000-3-2 EN 61000-3-3...
- Page 20 9919-101516-C Rev. 08-2017 Gecko Alliance 450 des Canetons, Québec (Qc), G2E 5W6 Canada, 1.800.78.GECKO © Groupe Gecko Alliance inc., 2017 All trademarks or registered trademarks www.geckoalliance.com are the property of their respective owners. Printed in Canada...
