Parameter
Part No.
Input Voltage
SR-2400P
100-240V AC
Product Size
53.0
DALI Power
SR-2400P
5
ISO9001：2000
Output Current
Output Voltage
16VDC
250mA max
65.0
Wiring diagram
220VAC
L
NC
N
Power input
SR-2400P
DALI Power Supply
DA+
DA+ DA-
DA-
0 1
9
8
2
(x1)
7
3
6
4
5
0 1
9
8
2
(x10)
7
3
6
4
GND
K1
K2
K3
K4
5
K1
K2
K3
K4
Safety & Warnings
1) The product shall be installed and serviced by a qualified person.
2) IP20.Please avoid the sun and rain. When installed outdoors, please ensure it is mounted in a water proof
enclosure.
3) Always be sure to mount this unit in an area with proper ventilation to avoid overheating.
4) Please check if the output voltage of any LED power supplies used comply with the working voltage of the
product.
5) Never connect any cables while power is on and always assure correct connections to avoid short circuits
before switching on.
6)
Please ensure that the cable is secured tightly in the connector
7) For update information please consult your supplier.
Power Supply
110V-230VAC
12-36VDC
DALI Controller
