- Page 1 Crestron CWD7134 Two-Way RF Transceiver Module Operations Guide...
- Page 2 équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante. Le présent émetteur radio , IC: 5683C-CWD7134, a été approuvé par Industrie Canada pour fonctionner avec les types d'antenne énumérés ci-dessous et ayant un gain admissible maximal et l'impédance requise pour chaque type d'antenne.
-
Page 3: Table Of Contents
Two-Way RF Transceiver Module: CWD7134 ..........1 Functions and Features ......................1 Specifications ..........................2 Physical Description – CWD7134 with External Antenna ............3 Ports ..........................4 Power/I-O ........................4 Setup ............................5 ... -
Page 5: Two-Way Rf Transceiver Module: Cwd7134
The module operates according to the IEEE 802.15.4 specification and can be configured to minimize the possibility of interference with other devices. The module receives RF signals from one or more Crestron devices and can transmit these signals over the air for further processing (depending on the application). -
Page 6: Specifications
Two-Way RF Transceiver Module Crestron CWD7134 Specifications The table below is a summary of specifications for the CWD7134. Specifications of the CWD7134 SPECIFICATION DETAILS Power Requirements 1.3 watts (5 Vdc @ 0.26 A) Operating Frequency 2400 MHz to 2483.5 MHz (802.15.4 compliant) -
Page 7: Physical Description - Cwd7134 With External Antenna
Crestron CWD7134 Two-Way RF Transceiver Module Physical Description – CWD7134 with External Antenna The module, shown below, consists of various components attached to a printed circuit board. The circuit board attaches an intended SMD mounting antenna. A MMCX reverse polarity female antenna... -
Page 8: Ports
These pins act as a pass through for power to be supplied to the wired devices. Power/I-O Pinout Signals 8-Pin Connector 4-Pin Connector Pin # Signal Pin # Signal Pin # Signal PB1/TXD PB2/RXD No Connect PC7 OUTPUT No Connect PC6 INPUT 4 Two-Way RF Transceiver Module: CWD7134 Operations Guide - DOC. 7497B... -
Page 9: Setup
20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.” Two-Way RF Transceiver Module: CWD7134 5 Operations Guide - DOC. 7497B... - Page 10 Crestron Electronics, Inc. Operations Guide – DOC. 7497B 15 Volvo Drive Rockleigh, NJ 07647 Tel: 888.CRESTRON 02.13 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
