Summary of Contents for Crestron CWD7191
- Page 1 Crestron CWD7191 Two-Way RF Transceiver Module Operations Guide...
- Page 2 équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante. Le présent émetteur radio , IC: 5683C-CWD7191, a été approuvé par Industrie Canada pour fonctionner avec les types d'antenne énumérés ci-dessous et ayant un gain admissible maximal et l'impédance requise pour chaque type d'antenne.
-
Page 3: Table Of Contents
Functions and Features ......................1 Specifications ..........................2 Physical Description – CWD7191 with a SMD Antenna ............3 Physical Description – CWD7191 with a Dipole Antenna ............4 Connectors ..........................5 Ports ..........................5 ... -
Page 5: Two-Way Rf Transceiver Module: Cwd7191
The module operates according to the IEEE 802.15.4 specification and can be configured to minimize the possibility of interference with other devices. The module receives RF signals from one or more Crestron devices and can transmit these signals over the air for further processing (depending on the application). -
Page 6: Specifications
Two-Way RF Transceiver Module Crestron CWD7191 Specifications The table below is a summary of specifications for the CWD7191. Specifications of the CWD7191 SPECIFICATION DETAILS Power Requirements 1.3 W (5 Vdc @ 0.26 A) Operating Frequency 2400 MHz to 2483.5 MHz (802.15.4 compliant) -
Page 7: Physical Description - Cwd7191 With A Smd Antenna
Crestron CWD7191 Two-Way RF Transceiver Module Physical Description – CWD7191 with a SMD Antenna The module, shown below, consists of various components attached to a printed circuit board. The circuit board attaches an intended SMD mounting antenna while a 25-pin D-SUB male connector is for the application-specific installation. -
Page 8: Physical Description - Cwd7191 With A Dipole Antenna
Two-Way RF Transceiver Module Crestron CWD7191 Physical Description – CWD7191 with a Dipole Antenna The module, shown below, consists of various components attached to a printed circuit board. A SMA reverse polarity female antenna port is located at the edge of the circuit board for the attaching of a dipole antenna while a 5-pin double row male connector is for the application-specific installation. -
Page 9: Connectors
Two-Way RF Transceiver Module Connectors Ports For the CWD7191 with a SMD antenna, the module contains a 25-pin D-SUB male connector and a 10-pin debug header. For the CWD7191 with a dipole antenna, the module contains a 5-pin double row male connector, a 10-pin debug header, and one antenna port. - Page 10 (Top View) NOTE: Pin 3 provides power to the circuit card. Power/I-O Pinout Signals Pin # Signal Pin # Signal PB2/RXD PB1/TXD SPI MISO SPI MOSI RESET SPI CLK 6 Two-Way RF Transceiver Module: CWD7191 Operations Guide - DOC. 7439C...
-
Page 11: Setup
Canada certification numbers of the module, proceeded by the words “Contains Transmitter Module”, or the word “Contains”, or similar wording expressing the same meaning as follows: Contains FCC ID: EROCWD7191 Contains IC: 5683C-CWD7191 Two-Way RF Transceiver Module: CWD7191 7 Operations Guide - DOC. 7439C... -
Page 12: Documentation
20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.” 8 Two-Way RF Transceiver Module: CWD7191 Operations Guide - DOC. 7439C... - Page 13 Crestron CWD7191 Two-Way RF Transceiver Module This page is intentionally left blank. Two-Way RF Transceiver Module: CWD7191 9 Operations Guide - DOC. 7439C...
- Page 14 Crestron Electronics, Inc. Operations Guide – DOC. 7439C 15 Volvo Drive Rockleigh, NJ 07647 Tel: 888.CRESTRON 03.13 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
