- Page 1 Crestron CWD6790 Two-Way RF Transceiver Module Operations Guide...
-
Page 2: Regulatory Compliance
To satisfy RF exposure requirements, this device and its antenna must operate with a separation distance of at least 20 centimeters from all persons and must not be colocated or operating in conjunction with any other antenna or transmitter. All brand names, product names and trademarks are the property of their respective owners. ©2010 Crestron Electronics, Inc. - Page 3 Crestron CWD6790 Two-Way RF Transceiver Module Contents Two-Way RF Transceiver Module: CWD6790 ..........1 Functions and Features ......................1 Specifications..........................2 Physical Description ........................2 Setup ............................4 Labeling ............................. 4 Documentation........................... 4 Contents • i Operations Guide - DOC. 7019A...
-
Page 5: Functions And Features
The module operates according to the IEEE 802.15.4 specification and can be configured to minimize the possibility of interference with other devices. The module receives RF signals from one or more Crestron devices and can transmit these signals over the air for further processing (depending on the application). -
Page 6: Specifications
Two-Way RF Transceiver Module Crestron CWD6790 Specifications The table below is a summary of specifications for the CWD6790. Specifications of the CWD6790 SPECIFICATION DETAILS Power Requirements 0.58 Watts (5VDC @ 0.115A) Operating Frequency 2400 MHz to 2483.5 MHz (802.15.4 compliant) Operating Ranges¹... - Page 7 Refer to the following table for pin assignments of the module interface connector. NOTE: Pin 1 provides power to the circuit card. Power/I-O Pinout Signals Pin # Signal Pin # Signal REMOTE_B/CONFIG TRIAC/RELAY ZERO_X 3.3V REMOTE_A/RELAY Two-Way RF Transceiver Module: CWD6790 • 3 Operations Guide - DOC. 7019A...
- Page 8 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.” 4 • Two-Way RF Transceiver Module: CWD6790 Operations Guide - DOC. 7019A...
- Page 9 Crestron CWD6790 Two-Way RF Transceiver Module This page intentionally left blank Two-Way RF Transceiver Module: CWD6790 • 5 Operations Guide - DOC. 7019A...
- Page 10 Crestron Electronics, Inc. Operations Guide – DOC. 7019A 15 Volvo Drive Rockleigh, NJ 07647 Tel: 888.CRESTRON 03.10 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
