This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON...
Crestron Isys™ tilt touchpanels (TPS-5000, TPS-6000, and TPS-4500 – refer to note on this page for this unit). Equipped with the TPS-XTXRF, the touchpanel is converted to an RF two-way wireless transceiver that communicates through an RF gateway/transceiver, TPS- RFGWX (sold separately) to the Crestron remote control system (herein referred to as the Cresnet system).
The latest versions of the guides can be obtained from the Downloads | Product Manuals section of the Crestron website (www.crestron.com). Physical Description The TPS-XTXRF, shown below, is housed in a black plastic enclosure. It replaces the original touchpanel base cover on the panel enclosure. TPS-XTXRF Physical Views 2 •...
In conclusion, the best condition for charging a battery is with the panel powered down. Furthermore, the optimum operating conditions for extending battery charge requires that the brightness be kept to a minimum, minimizing the standby and power down timeouts, and avoid overheating/freezing. Two-Way RF Transceiver Module: TPS-XTXRF • 3 DETAILS...
Page 8
Downloads | Product Manuals section of the Crestron website (www.crestron.com). The firmware upgrade files can be obtained from the Downloads | Software Updates section of the Crestron website. Refer to NOTE after last footnote on page 5. Crestron recommends that the latest firmware be loaded into the TPS-RFGWX and associated touchpanel(s).
Page 9
ST-CP Update File Weight of TPS-XTXRF (no touchpanel) Weight: 15.40 oz (0.44 kg) NOTE: Crestron software and any files on the FTP site are for Authorized Crestron dealers only. New users may be required to register in order to obtain access to certain areas of the FTP site.
Two-Way RF Transceiver Module Installation The only tools required for installation of the TPS-XTXRF onto an Isys™ tilt touchpanel are a #1 Phillips screwdriver and a grounding strap (or grounded workstation). CAUTION: The TPS-XTXRF and the touchpanel contain ESD sensitive devices.
Page 11
SEE MANUAL USE POWER PACK PW-2420RU TPS-6000 ZA***** C000000 7. Place the touchpanel upright on the work surface. 8. As shown below, remove the touchpanel base cover by raising it upwards and rearward. Two-Way RF Transceiver Module: TPS-XTXRF • 7...
Page 12
NOTE: If the TPS touchpanel is equipped with an optional TPS-XVGA or TPS-XVGA-BV expansion card, the fan assembly on the card must be removed because it interferes with the placement of the TPS-XTXRF. Removal will not introduce cooling problems because the TPS-XTXRF has fans for adequate air circulation.
Page 13
NOTE: If the TPS touchpanel is equipped with an optional TPS-XVGA or TPS-XVGA-BV expansion card, temporarily removing the card makes installation of the TPS-XTXRF cable connectors easier. However, re-installation of the card requires a #1 Phillips screwdriver (1.5” length). Installation Diagram 5 of 12 - Position TPS-XTXRF onto Touchpanel Operations &...
Page 14
Installation Diagram 6 of 12 - Attach Large TPS-XTXRF Connector Installation Diagram 7 of 12 - Spread Large Connector Wires NOTE: The TPS-XTXRF ribbon cable connector has a key to ensure a proper fit with the small connector of the touchpanel. When installing the ribbon cable connector, verify that the key slides into the slot of the mating connector.
Page 15
Two-Way RF Transceiver Module RED STRIPE SLOT 15. Refer to the diagram on the next page. Align the TPS-XTXRF threaded screw inserts with the holes of the touchpanel base plate and lower the TPS-XTXRF onto the touchpanel base. Two-Way RF Transceiver Module: TPS-XTXRF • 11...
Page 16
Two-Way RF Transceiver Module Installation Diagram 10 of 12 - Lower TPS-XTXRF onto Touchpanel Base Installation Diagram 11 of 12 - Install TPS-XTXRF Mounting Screws 12 • Two-Way RF Transceiver Module: TPS-XTXRF 16. Hold the TPS-XTXRF in place and position the touchpanel face-down onto a padded surface to prevent scratching of the screen.
Page 17
19. Refer to the diagram below. By hand, thread the antenna onto the antenna mounting post to finger-tight. 20. Apply power to the touchpanel. There are four ways to operate the TPS-XTXRF equipped touchpanel. First, a charged TPS-XBTP Battery Pack can be installed into the touchpanel directly. Secondly, the TPS-XTXRF equipped touchpanel can be properly positioned on the TPS-XDS Docking Station with or without a TPS-XBTP installed.
This will help in determining whether there is a programming problem, RF setting conflict or RF interference in the environment. Configure TPS-XTXRF Equipped Touchpanel To create a program with a TPS-XTXRF, refer to the table below for initial configuration information. Configure TPS-XTXRF Program...
STX1550C_*.SMW. Configuring the Touchpanel for Operation The touchpanel with the TPS-XTXRF installed can operate as a Cresnet or RF device. The operation of the touchpanel is determined by the attachment of the NET/VIDEO cable to the touchpanel. To use the touchpanel as a Cresnet wired unit, connect the NET/VIDEO cable to the NET/VIDEO port of the touchpanel.
Page 20
Two-Way RF Transceiver Module RF Configuration Crestron Isys To configure the TPS-XTXRF equipped touchpanel for RF communication, it is necessary to access a series of setup screens on the touchpanel. NOTE: For additional touchpanel configuration information, consult the appropriate Isys from the Downloads | Product Manuals section of the Crestron website (www.crestron.com).
For the TPS-XTXRF equipped touchpanel, analog join number 17507 may be used for a TPS-BTP battery gauge. There is also another analog join number 17514 that is used to determine the state of the battery pack.
NOTE: To minimize system diagnostics and troubleshooting, Crestron recommends defining the touchpanel as a wired unit in SIMPL Windows, then test functionality as a wired network device prior to testing the TPS-XTXRF transceiver operations. This will help in determining whether there is a programming problem, RF setting conflict or RF interference in the environment.
Future Updates As Crestron improves functions, adds new features, and extends the capabilities of the TPS-XTXRF, additional information may be made available as manual updates. These updates are solely electronic and serve as intermediary supplements prior to the release of a complete technical documentation revision.
