5.
once the installation is complete, use a 3/4 inch wrench to screw down the UpS leveling feet located
next to the four casters, until the unit is no longer resting on the casters.
6.
the UpS generates and can radiate radio-frequency energy during operation. Although rFi noise
filters are installed inside of the unit, there is no guarantee that the UPS will not influence some
sensitive devices that are operating near by. if such interference is experienced, the UpS should be
installed farther away from the affected equipment and/or powered from a different source than that
of the affected equipment.
THE METAL OF CONDUIT IS NOT AN ACCEPTABLE GROUND.
7.
it is the responsibility of the installer of this equipment to provide a suitable disconnect for the Control
panel supplying power to this equipment.
this disconnect must:
be suitable for the Voltage and Full load Ampere rating of all downstream equipment supplied by
the panel;
the supply disconnecting device shall be one of the following types:
•
Switch-disconnector, with or without fuses, in accordance with ieC 60947-3, utilization
category AC-23b or dC-23b
•
As above, except one that has an auxiliary contact that in all cases causes switching devices
to break the load circuit before the opening of the main contacts of the disconnector.
•
A circuit breaker suitable as an isolation device per ieC 60947-2
•
Any other switching device in accordance with an ieC product standard that also meets the
isolation requirements of ieC 60947-1 and is appropriate for on-load switching of motors or
other inductive loads;
be approved for use as a disconnect for the country in which this equipment is installed.
be provided with a lock out tag out capability in the off (down) position.
8.
Allow 5 minutes after power is removed for internal capacitors to fully discharge before attempting
to service the unit.
9.
The user should provide output over-current protection for hardwired UPS systems. See Specifications
section on pages 19 and 22 for the device rating.
10.
After ensuring that all power sources are turned off and isolated in accordance with established
lockout/tagout procedures, connect the power source wiring of the correct voltage to the input
terminals of the UpS.
11.
the end user must supply suitable strain relief for the power cord and the cord must extend a
distance of 1/2 diameter beyond the clamp.
12.
Connect the output terminals of the UpS to the load in line with local wiring regulations. Size the
branch circuit conductors in accordance with neC table 310.16.
8
WARNING
1600Xp Series installation and operation manual
