- Page 1 SWIT ELECTRONICS CO., LTD. Model: CM-S73H 7” Full HD High Bright LCD Monitor User Manual Please read this user manual throughout before using Ver： A...
-
Page 2: Preface
All internal technologies of this product are protected, including device, software and trademark. Reproduction in whole or in part without written permission is prohibited. All brands and trademarks of SWIT Electronics Co., Ltd. are protected and other relative trade- marks in this user manual are the property of their respective owners. -
Page 3: Table Of Contents
Maintenance Warning 1. In order to reduce the risk of fire and electrical shock, do not lay this product in rain or damp places. 2. Please keep away from the strong magnetic field; it may cause the noise of the video and audio signals. -
Page 4: Packing List
Carrying case Introduction CM-S73H adopts TFT LCD panel, with resolution 1920×1200 and wide viewing angle H160°／V120°. It supports 2 x 3GSDI (Level A/B), 1 x HDMI2.0 (4K display) input. It also supports 1x 3GSDI, 1 x HDMI and 1 x analog audio loop through output. -
Page 5: Operation Instruction
Operation Instruction (10) ⑴ Button Source: Signal selection button （HDMI、 SDI1、 SDI2） User definable function keys （ F1～F3） User can set F1～F3 keys to corresponding function for quick operation according to their needs. For example： User can set F1 to “Focus Assistant” , and press F1 to directly switch the focus assistant parameter, the sequence is “Red→Blue→Off”... -
Page 6: Screen Display
⑻ Video Signal Interface HDMI-IN： HDMI input (HDMI-A connector) HDMI-OUT： HDMI output (HDMI-A connector) SDI-IN1： 3G/HD/SD SDI input (BNC connector) SDI-IN2： 3G/HD/SD SDI input (BNC connector) SDI-OUT： 3G/HD/SD SDI output (BNC connector), the monitor choose fixed SDI-IN1 signal to loop output. -
Page 7: Zoom-In And Mapping
Zoom-in and mapping Zoom-in steps Left/Right mapping Up/Down mapping Peaking precision Mapping indition 1.2 X Set “Zoom-in” to function keys, and enable zoom-in mode, the OSD displays as above. 1、 Zoom-in steps operation Scroll the menu key up and down you can quickly zoom in the video by the following rates: 1.2x, 1.5x, 1.8x, 2.0x, 2.4x, 2.6x, 2.8x, 3.0x, without black waiting. - Page 8 Introduction of audio and video functions 16-ch embedded audio meters Under 3G/HD/SD SDI, it displays 16 channels embedded audio meters. Under HDMI, it displays 2 channels embedded audio meters. The audio meter is green, and will turn yellow when audio exceeds -20dB, and turn red when audio exceeds -9dB.
-
Page 9: Main Menu
Main menu CM-S73H has OSD to adjust the parameters and settings, for example: Picture, color temp., function keys, etc. 1. Press “MENU” button, the main menu will popup from the left top of the screen. The selected main menu highlights in yellow. - Page 10 Submenu introduction （the default values are marked with underline ） 1. Exit & Status Displays the current status, the details are as down below: 1080p@50Hz Exit&Status HDMI Factory User Profile Color Temp 6500K Normal Scan Mode Freeze Frame Off Off Odd/Even Frame Time code Focus Assist...
- Page 11 4、 Function key To define the F1～F3 function keys Function Key Exit Time Code Focus Assist Zebra Max Backlight Freeze Frame Scan Mode *1 Function keys F1-F3 can be set as the down below functions: Time code, Zebra, Audio Bar, False Color, AFD, H/V Delay, R/G/B/Mono, Marker, Color Bar, UMD, Audio Alarm, Focus Assist, Aspect Ratio, Scan Mode, Zoom Mode, Mute, Freeze Frame, Flip Mode, Color Temp.
- Page 12 6、 UMD Exit RS485 Address Position Top,Bottom Size Normal Color Red,White,Black,Blue,Green,Yellow Display Type Source ID Baud Rate 38400 Parity Even Serial Port RS485 Source ID CAMERA 1 Set “UMD” : ⑴ Select “Source ID” (2) The underline flashes as a reminder on the bottom of the first letter. Revolve "MENU" to select the letters;...
- Page 13 8. Audio Audio Exit Audio Bar Off,On Bar Frame Off,On Bar Position Top Right,Bottom Left,Bottom Right,Top Left Low,Off,High Bar Blending Audio Alarm Off,On Select Channel Channel 1-2,1-8,1-16 Left Channel CH1-CH16,CH1 Right Channel CH1-CH16,CH2 *1 When “Bar Frame” is set to “Off” , only the audio meter will be displayed. When “Bar Frame”...
- Page 14 When set to “Off” , update model will not be supported. *2 Logo When powered on, the screen will display SWIT logo. *3.*4 Update Driver/ Kernel ⑴ Open the power supply, plug the U disk with upgrading programma into the USB port on the rear of the monitor；...
- Page 15 ITU Rec.709 mode to monitor. A ” User-Log” is provided for user defined LUT converting to Rec.709. *2 HDR CM-S73H supports three HDR modes: PQ_709、 HLG_709、 S-Log3. *3 Color measurement Set the Color measurement parameter to “On” before color calibration, make sure the parameter set to “Off”...
- Page 16 12. OSD Exit English,Chinese OSD Language OSD Blending Low,Medium,High,Off OSD Duration 10Sec,15Sec,30Sec,60Sec OSD Zoom Off Key Led Brightness Low,Medium,High,Off Tally-R Brightness High Tally-G Brightness High Soft-Tally Position Soft-Tally Blinking 13. Key Inhibit Key Inhibit Exit Off,On Key Inhibit When the “Key inhibit” is set to “on” , there is no response when all the buttons except “MENU” is pressed, the sreen will be displayed as “...
-
Page 17: Specification
Specification LCD Performance Size 7 inch Display area 151.2×94.5 mm Resolution 1920×RGB×1200 Color 8 bit Aspect ratio 16:9／4:3 Brightness* 3000 cd／m Contrast 1200:1 Viewing angle Horizontal / Vertical: 160°／160° Input/Output HDMI input HDMI×1 3G/HD/SD-SDI input BNC×2 Input USB×1 HDMI output HDMI×1 Output 3G/HD/SD-SDI loop output... -
Page 18: Trouble Shooting
Trouble-shooting symptom Possible causes Solution Please check if the power is connected, and then The power is not turned on press “POWER” button to turn on the monitor Reconnect to power supply Unstable power voltage BNC or HDMI cable loose contact or not correctly Check and correctly connect the BNC or HDMI cable connected... - Page 19 Technological Development Zone, Nanjing 210038, P.R.China Tel: +86-25-85805753 Email: contact@swit.cc SWIT Electronics Europe GmbH Add: Hochstr. 17, 47228 Duisburg, Germany Tel: +49(0)20659799339 Email: info@swit-europe.com SWIT Electronics America, Inc Add: 3350 Scott Boulevard 61-02, Santa Clara, CA 95054, USA Tel: (408)260-8258, 1-866-986-SWIT(7948) Email: info@swit.us...
