Function Range
5.000Hz
Frequency
50.00Hz
500.0Hz
5.000kHz
50.00kHz
500.0kHz
5.000MHz
Sensitivity: >0.5V rms min. [ 1MHz; >3V rms > 1MHz
NOTE:
o
Accuracy is stated at 65 F to 83
Diode Test Test current of 0.3mA typical, open circuit voltage 1.5V DC typical
Continuity Check Audible signal will sound if the resistance is less than 150Ω
(approx.), test current <0.3mA
Temperature Sensor Requires type K thermocouple
Input Impedance 7.8MΩ
AC Response Average responding
ACV Bandwidth 50Hz to 400Hz
Display 4,000 count liquid crystal
Overrange indication "OL" is displayed
Auto Power Off 30 minutes (approximately)
Polarity Automatic (no indication for positive); Minus (-) sign for negative
Measurement Rate 2 times per second, nominal
Low Battery Indication "
voltage
Battery Two AAA batteries
Fuses mA, µA ranges; 0.5A/660V ceramic fast blow
A range; 10A/250V ceramic fast blow
Operating Temperature 41°F to 104°F (5°C to 40°C)
Storage Temperature -4°F to 140°F (-20°C to 60°C)
Operating Humidity Max 80% up to 87°F (31°C) decreasing linearly to 50% at 104°F
(40°C)
Storage Humidity <80%
Operating Altitude 7000ft. (2000meters) maximum.
Weight 0.5lb (225g) (includes holster).
Size 5.31" x 2.67" x 1.7" (135 x 68 x 43mm)
Safety This meter is intended for indoor use and protected, against the
users, by double insulation per EN61010-1 and IEC61010-1 2nd
Edition (2001) to CAT II 1000V & CAT III 600V; Pollution Degree 2.
The meter also meets UL 61010-1, Second Edition (2004),
CAN/CSA C22.2 No. 61010-1, Second Edition (2004), and UL
61010B-2-031, First Edition (2003)
Approvals UL CE
UL Listed The UL mark does not indicate that this product has been
evaluated for the accuracy of its readings.
Resolution Accuracy
0.001Hz
±(1.5% reading + 5 digits)
0.01Hz
0.1Hz
0.001kHz
±(1.2% reading + 3 digits)
0.01kHz
0.1kHz
0.001MHz ±(1.5% reading + 4 digits)
o o o
F (18 C to 28 C) and less than 75% RH.
" is displayed if battery voltage drops below operating
