Page 3: Installation
INSTALLATION Water Inlet Connection: This equipment is to be installed to comply with the applicable Federal, State, or local plumbing codes having jurisdiction. In addition: 1. A quick disconnect water connection or enough extra coiled tubing (at least 2 times the depth of the unit) so that the machine can be moved for cleaning underneath. - Page 4 The Automatic Dispense Buttons are factory programmed to dispense 1.3 oz. of water per second. PRODUCT STRENGTH ADJUSTMENTS: The JAVA 2-QB units have variable speed control auger motors with variable speed of 10 to 90 RPM]. Drink or Product Strength can be changed by adjusting the Gram Throw Dial on inside door panel.
- Page 5 CLEANING AND SANITIZING: SANITIZING: All food dispensing units should be sanitized periodically. All parts to be sanitized must be cleaned first. To prepare a sanitizing solution: ADD 2 TSP. OF LIQUID CLOROX BLEACH (5.25% CONCENTRATION) TO 1 GALLON OF WATER AT ROOM TEMPERATURE (70°F - 90°F). Soak all parts for a minimum of 3 min.
- Page 13 TEACH-ME TIMER COFFEE D.C. AUGER MOTOR SPEED CONTROL DISPENSE VALVE WATER INLET VALVE VACUUM FAN RED WIRE HI-LIMIT "C" "D" TERMINAL BLOCK 3 PIN CONNECTOR WARMER 100 W POWER STOP SWITCH RINSE SWITCH LIQUID LEVEL CONTROL WATER LEVEL PROBES WATER CONTACTOR "B"...
- Page 14 TEACH-ME TIMER COFFEE D.C. AUGER MOTOR SPEED CONTROL DISPENSE VALVE WATER INLET VALVE VACUUM FAN HI-LIMIT TERMINAL BLOCK 3 PIN CONNECTOR WARMER 100 W POWER STOP SWITCH SPEED RINSE CONTROL SWITCH LIQUID LEVEL CONTROL WATER LEVEL PROBES WATER READY TEACH-ME TIMER DECAFF D.C.
- Page 15 CARRIER CONVERSION KIT # SK79Q FOR MODELS ORIGINALLY EQUIPPED WITH AIRPOT DISPENSER TO CONVERT TO CAR-1 CARRIER DISPENSER: 1. Disconnect Electrical Power to the Machine. 2. Remove Tower Cover SH62Q and Base Cover SH59A (Used with Airpot Dispenser). 3. Make electrical connection to Warmer Deck SH73Q (2 pin plug and socket). 4.
- Page 16 FOR MODELS ORIGINALLY EQUIPPED WITH CAR-1 CARRIER DISPENSER TO CONVERT TO AIRPOT DISPENSER: 1. Disconnect Electrical Power to the Machine. 2. Remove Tower Cover SJ73Q and Warmer Deck SH73Q (Used with Carrier Dispenser). 3. Disconnect electrical connection to Warmer Deck (3 pin plug and socket), Insulate with cap plug B155A and tape connector back into the main harness.
- Page 17 RETROFIT CARRIER KIT # SK66Q FOR JAVA 2-QB SHIPPED PRIOR TO APRIL 2002...
