OPERATION MANUAL
MODEL:
FE-100G
SPECIFICATIONS
INSTALLATION
MAINTENANCE TIPS
REPAIR PARTS LIST
WIRING DIAGRAMS
GAS SPECIFICATIONS
MODEL NO.
FE-100G
DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS AND
LIQUIDS IN THE VICINITY OF THIS OR ANY OTHER APPLIANCE.
THIS INSTALLATION MUST CONFORM WITH THE NATIONAL FUEL GAS CODE,
WARNING: IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE
OR MAINTENANCE CAN CAUSE PROPERTY DAMAGE, INJURY OR DEATH. READ
THE INSTALLATION, OPERATING AND MAINTENANCE INSTRUCTIONS
THOROUGHLY BEFORE INSTALLING OR SERVICING THIS EQUIPMENT.
TH
43-05 20
NATURAL GAS
BTU/HR @ 3.5" W.C.
32,000
FOR YOUR SAFETY
ANSI Z223.1 (LATEST EDITION).
CECILWARE CORPORATION
AVENUE, LONG ISLAND CITY, NY 11105-1295
• 718 932-1414
AUTOMATIC GAS
COFFEE URN
PROPANE GAS
BTU/HR @ 10" W.C.
32,000
N529A 08/99 DS
