Document Name:
Traffic Monitor user's manual
PART TWO – INSTALLATION
1.
2.1 Mechanical installation
LX Traffic Monitor fits in a standard 80 or 57 [mm] // 3.15 or 2.25 [˝] instrument hole so no extra cut out is
required. To fit the LX Traffic Monitor in the instrument panel, unscrew the two mounting screws (black)
with a screwdriver and remove the two rotary knobs.
To remove the rotary knobs do not use force. First, remove the press-in cover to access the screw. Loosen
the screw and pull off the knob. Place the LX Traffic Monitor in the hole in the instrument panel and first
screw in the two black screws and then install the two rotary knobs.
Don't forget to tighten the screws in the knobs and put the press-in cover back on.
2.
2.2 Electrical installation
FLARM 1 (RJ45)
Pin number
Description
1
Power input
2
Power input
3
Not used
4
GND
5
RS 232 data in
6
RS 232 data out
7
GND
8
GND
FLARM 2 (RJ45)
Pin number
Description
1
Power input
2
Power input
3
Not used
4
GND
5
RS 232 data out
6
RS 232 data in
7
GND
8
GND
Version:
1.8
Page 8
AUDIO (3.5 mm jack)
Standard 3.5 mm jack
with audio out
