Environmental Data - LX Navigation Traffic monitor 57 User Manual

Document Name:
Traffic Monitor user's manual
3.

5.2 Environmental data

Description
Temperature / Altitude D1
Low Ground Survival Temperature
Low Operating Temperature
High Ground Survival Temperature
High short Time Operating Temperature
High Operating Temperature
In Flight Loss of Cooling
Altitude
Temperature Variation
Humidity
Shock
Vibration
Explosion Proofness
Water Proofness
Fluids Susceptibilities
Sand and Dust
Fungus Resistance
Salt Spray
Magnetic Eect
Power Input(DC)
Voltage Spike Conducted
Audio Frequency Conducted Susceptibility
Induced Signal Susceptibility
Radio Frequency Susceptibility
Conducted Susceptibility Emission of RF
Lightning Induced Transient Susceptibility
Lightning Direct Effects
Icing
Electrostatic Discharge (ESD)
Fire, Flammability
Environmental tests are performed in accordance with RTCA DO-160
Section Category
4.0 D1
4.5.1 D1
4.5.1
4.5.2 D1
4.5.2 D1
4.5.3 D1
4.5.4 Z
4.6.1 D1
5.0 B
6.0 A
7.0 B
8.0 U/U2
9.0 X
10.0 X
11.0 X
12.0 X
13.0 X
14.0 X
15.0 Z
16.0 B
17.0 B
18.0 B
19.0 X
20.0 T
21.0 M
22.0 A2XXX
23.0 X
24.0 X
25.0 A
26.0 X
Version: 1.8
Page 28
Conditions
-55°C
D1 -40°C
+85°C
+70°C
+55°C
No auxiliary cooling required
90,000 ft
Vibration curve F/F1 (robust
vibration, helicopter)
not tested
not tested
not tested
not tested
not tested
not tested
Less than 0.3m
not tested
Radiated Susceptibility T
not tested
not tested
Enclosure made of
aluminum (Al) sheet
