3 Do not use extension cords to connect the dispenser. 4 Do not operate the dispenser unless all panels are restrai- ned with screws. 5 Do not obstruct air intake and discharge openings: 15 cm (6”) minimum air space all around the dispenser. 6 Do not put objects or fingers in panels louvers and faucet outlet.
Page 4
ARCTIC COMPACT 12-20 UL 6 Gravity faucet: extract the piston and then remove the dispensing handle (see figure 3). figure 3 7 Slide drip tray out and empty it. 5. 3. 2 CLEANING IMPORTANT Do not attempt to wash any machine components in a dishwasher.
5 Place bowl on the unit. Wet the gasket for ease of insertion. Please take care that the hook on the backside of the bowl be inserted properly in its seat on the upper drip plate. (see figure figure 7 6 Use fresh product to chase any remaining sanitizer from the bowl(s).
Page 6
ARCTIC COMPACT 12-20 UL 1 CARACTERISTICAS TECNICAS Contenedores transparentes desmontables Capacidad de cada contenedor, aproximada Dimensiones: ancho largo alto 12 lt 20 lt Peso neto, aproximado 12 lt 20 lt Peso bruto, aproximado 12 lt 20 lt Termostatos regulables Motocompresor hermético Condensador a ventilación forzada...
Page 7
5 No impedir el flujo de aire de refrigeración, dejar un espacio libre de por lo menos 15 cm alrededor del distribuidor. 6 No introducir los dedos u objetos en las ranuras de los paneles y en la apertura del grifo. 7 No desmontar el contenedor, no quitar los mezcladores o paneles para limpieza o manutención sin cerciorarse que el distribuidor esté...
Page 8
ARCTIC COMPACT 12-20 UL 5 Grifo con tubo de goma: empujar la palanca mando grifo (1) y sacar (2) el tubo goma de salida desde su situación vertical en el fondo del contenedor (ver figura 2). figura 2 6 Grifo en acero inox por gravedad: Sacar el pisón y desmontar la palanca mando grifo (ver figura 3).
abajo la extremidad del tubo de goma hasta ajustarlo completamente (ver figura 4). figura 4 3 Grifo en acero inox por gravedad: montar la palanca mando grifo y enfilar el pisón unido a la su junta (ver figura 5). figura 5 4 Poner la junta al evaporador, de modo que el borde de mayor ancho se quede en contacto con el plano recoge-gotas (ver figura 6).
Page 10
ARCTIC COMPACT 12-20 UL SPARE PARTS LIST DESCRIPCION PIEZAS DE REPUESTO...
Page 11
20 It bowl cover 00651 12 It bowl cover 00651 20 It bowl 00652 12 It bowl 00651 Faucet spring 00030 Bowl gasket 00653 Impeller 33900-01201 Plastic I-beam for connection 00655 Central pivot 00656 Central pivot OR 00112 Capacitor 00658 Clip 10554-45000 Faucet piston...
