its power source. ATTENTION In case of damages, the power cord must be replaced by qualified personnel only in order to prevent any shock hazard. 8 This unit is not meant to be used outside. 9 This unit is not to be installed in areas subject to water- spouts..
Page 4
ARCTIC DELUXE UL side) up and off bowl gasket (see figure 1). figure 1 3 Remove the bowl gasket. 4 Remove the pump impeller from its location. 5 Pinch tube faucet: push the dispensing handle (1) and take the pinch tube off from its seat (2) (see figure 2). figure 2 6 Gravity faucet: extract the piston and then remove the dispensing handle (see figure 3).
5. 3. 4 ASSEMBLY 1 Slide the drip tray into place. 2 Pinch tube faucet: push the dispensing handle (1) and insert the pinch tube into its vertical seat in the bowl bottom(2). Lightly pull the pinch tube end downwards til itl is well arranged (3) (see figure 4).
7 No desmontar el contenedor, no quitar los mezcladores o paneles para limpieza o manutención sin cerciorarse que el distribuidor esté desenchufado del suministro de corriente. ATTENCION Si el cable de alimentación está dañado, debe ser substi- tuito por el fabricante o desde su servicio de asistencia técnica o, en cualquier caso, por una persona cualifi- cada con el fin de evitar cualquier tipo de riesgo.
Page 8
ARCTIC DELUXE UL 2 Quitar el contenedor vacío levantándolo por la parte anterior y desprendiendolo de la junta (ver figura 1). figura 1 3 Quitar la junta del contenedor. 4 Sacar la turbina pompa. 5 Grifo con tubo de goma: empujar la palanca mando grifo (1) y sacar (2) el tubo goma de salida desde su situación vertical en el fondo del contenedor (ver figura 2).
abajo la extremidad del tubo de goma hasta ajustarlo completamente (ver figura 4). figura 4 3 Grifo en acero inox por gravedad: montar la palanca mando grifo y enfilar el pisón unido a la su junta (ver figura 5). figura 5 4 Poner la junta al evaporador, de modo que el borde de mayor ancho se quede en contacto con el plano recoge-gotas (ver figura 6).
Page 10
ARCTIC DELUXE UL SPARE PARTS LIST DESCRIPCION PIEZAS DE REPUESTO 20 It bowl cover 00651 12 It bowl cover 00651 Bowl gasket 00653 Plastic I-beam for connection 00655 Central pivot 00656 Tapa contenedor 20 It Tapa contenedor 12 It Junta contenedor Perfil de union Pivote central...
Page 11
Central pivot OR 00112 Motor magnet 00117 Motor bracket 00116 Motor 00045 Back panel 20 l bowl for pump 00652 Spray tube for 12 l bowl 22900-00201 12 l bowl for pump 00657 Impeller 60Hz 00671 Faucet spring 00030 Bent tube for 20 l bowl 00672 Faucet piston 00077...
