3
2
1
4000601-H, 4000602-H
3
Mid Clamp
30 - 50 mm module frame height
4000090 / 4000050-H
4
End Clamp or Yeti Clamp
30 - 50 mm module frame height
4000019, 4000020
5
CrossRail
44-X shown & PNs listed
9
