- Page 1 Connecting Strength K2 Multi Mount QUICK GUIDE...
-
Page 2: Tools Overview
Components 4000282/4000284 4000135/4000145 4000310 K2 Multi Mount K2 Cross Clamp DR #14 x 3" x 5/16 Hex Head Screw Multiple PNs 4000769/4000770 CrossRail K2 Rail Runner Kit Tools Overview Chalk Line Tape Measure Drill Heat Gun ≥ 3.0 m ≥ 6.0 m Torque Wrench 13mm Socket 5/16"... - Page 3 Assembly Option 1: Installing with T-Bolts Corner out and mark array on roof. Snap chalk lines for rail location within shingle course. (Refer to module manufacturer frame clamping zones). Mark mounting locations over rafters and chalk lines within shingle course. Refer to engineering letters for allowable mount spacing. It is best practice to stager mounts.
- Page 4 Part B: Mount Placement and Installation for Rafter Connection Disclaimer: To maintain flashing performance, avoid installation when the roof and/or butyl temperature is below 22F or above 176F. K2 EverSeal must be installed on a dry surface.22F or above 176F. K2 EverSeal must be installed on a dry surface.
- Page 5 Part C: Mount Placement and Installation for Deck Connection To maintain flashing performance, avoid installation when the temperature of the roof and/or butyl is below 22F or above 176F. K2 EverSeal must be installed on a dry surface. For deck attachments, follow steps in B2, but only use “4000310 - #14 x 3in x 0.3125in Hex Head Screw”.
- Page 6 Position and install rail on back side of K2 MultiMount towards the ridge, as shown in the image. Insert T-Bolt through slot and into side channel of CrossRail. Turn the T-Bolt clockwise ensuring that the mark at the end of the shaft is vertical, indicating proper alignment. Tighten to 25.8 ft-lbs (35 Nm).
- Page 7 Line up mounts horizontally up the roof facing the ridge on a chalk line facing the Multi Mount serrations. Take your rail and push it agaisnt the Rail Runner; do not tighten up the Runner it should be a little loose so the rail can easily run through smoothly.
- Page 8 With the rail mounted inside the Rail Runner, adjust to your desired height and fasten. Torque the Rail Runner bolt to 12ft-lbs [16.27 Nm]. The Rail Runner is designed to support your rail and provide maximum engagement.
- Page 9 Place the rest of the Multi Mounts with the Rail Runner repeating from Step 2, to complete your installation.
- Page 10 Connecting Strength K2 Systems, LLC Everest Solar Systems S de RL de CV 4665 North Ave. Suite I • Oceanside, CA 92056 • Calle Coral 2628 Int. 1 • Col. Residencial USA +1.760.301.5300 • infous@k2-systems.com Victoria, CP 44560 • Guadalajara, Jal.• México www.k2-systems.com/en-us...
