1.1 Features of the logger

Congratulations on purchasing the iLog series of data loggers! These portable battery powered
data loggers allow recording information and saving measurements to a 4MB flash memory for
later retrieval.
The internal lithium battery provides up to 12 years of instantaneous logging operation when
sampling at interval of one minute.
An iLog data logger can be manipulated by SiteView Windows software for data downloading,
logging management, and property configuration. It has both TTL-compatible serial port and
USB interface for different communications requirements.
An iLog data logger features a wide sampling interval range from 20 milliseconds to 12 hours,
providing alternative to data acquisition devices and paper chart recorders.
An iLog data logger provides alarm outputs controlled by the low and high programmable
alarm thresholds of each enabled channel. The alarm control outputs can be used to turn on/off
external alarm devices such as strobe lights, sirens or alarm telephone diallers.
An iLog data logger also has an excitation control output used to switch the power supply of the
external transducer/transmitter.
An iLog data logger contains one internal thermistor channel, and one external process signal
channels. The 16-bit analog-to-digital converter makes the measurements more precise and
accurate.
And iLog data logger also has a rugged, splash resistant aluminum enclosure.

1.2 Approvals

All iLog Series data loggers are in conformity with the EN standard(s) listed below:
EN 61000-6-2:[2005]

General standards – Immunity for industrial environments
EN 61000-6-3:[2007]

