Specifications; Common Specifications - Microedge Instruments iLog Series User Manual

6 . S p e c i f i c a t
6 . S p e c i f i c a t

Common Specifications

Alarm
Channel Alarms
Alarm Outputs
Alarm-On Delay
Alarm Indicator
On-board Memory
Capacity
Data Retention
Sampling & Logging
Sampling Interval
Logging Mode
Logging Activation
Communications
Interface
Baud Rate
Battery
Power
Life Cycle
Software
[2]
SiteView
Software Requirements
iLog Data Loggers User's Manual
i o n s
i o n s
Two editable alarm thresholds per channel.Alarm controls
Alarm1, A2/EXT outputs and send out over comm. interface.
Alarm1 & A2/EXT can be configured as alarm outputs.
Alarm-On: MOSFET(N-Channel) switch on
Alarm-Off: MOSFET(N-Channel) switch off
Max Power: 200mA @ 24VDC.
With purchase of SiteView software, iLog can report alarm status
to host PC via USB, Modem or Ethernet Device Server.
Programmable 0 - 10 minutes delay with 1-minute increment.
On-board LED lights in red when in alarm state.
4 Mega-bytes (2 Mega measurements)
Over 20 years
[1]
20 milliseconds
Stop recording or FIFO when memory is full.
Programmable instant, start delay or field push button activation.
USB (Mini-USB-B) (USB-A-mini USB-B Cable included)
AUX(RJ11) for direct TTL level communications
With purchase of DeviceServer, iLog can be connected to Ethernet
for remote access.
Auto-detect baud rate from 2400 to 115200 bps on both USB
and AUX.
Built-in 3.6V Lithium Battery.
12 years for other models based on 1 minute sampling interval.
Configuration, downloading, scheduled downloading, plotting,
real-time plotting, custom calibration and custom equation
Computer with 1.0 GHZ or faster processor
256 MB Memory or higher
1.0 GB of available hard-drive space or higher
Windows XP with SP2 or later, Vista, Window 7
At least one USB port or one COM port.
to 12 hours for other models, user selectable.
Page 62/63
