Physical
Material
PCB Treatment
Dimension
Weight
Mounting
Others
LED Indicator
Excitation Control
Operating Environment
Clock Accuracy
Approvals
[1]: Maximum enabled channels: 1 for 20ms interval, 2 for 30ms, 8 for 40ms or bigger interval.
[2]: Sold separately.
Logging Capacity
Sampling
Enabled
Interval
Channel
1 minute
1
1 minute
2
10 seconds
1
10 seconds
2
iLog Data Loggers User's Manual
Aluminum Enclosure.
Conformal coating
88 X 64.2 X 24 mm
3.46 X 2.53 X 0.95 Inches
150g
Probe/wall-mount holes for hanging/mounting.
Tri-Color LED: (can be disabled for power saving)
Normal Sampling: green when sampling.
Alarm: red when sampling.
Low Battery: amber when sampling.
A2/EXT terminal strip can be configured as excitation control
output for driving the power of connected devices.
Warm-up Interval settings: 10 to 240 seconds with 10-second
increment.
(-40 to + 158°F
-40 ~ +70°C
±1 minute per month
CE, FCC
Logging
Capacity
3.98 years
727 days
242 days
121 days
), 0 ~ 95 %RH non-condensing.
Sampling
Enabled
Interval
Channel
1 second
1
1 second
2
100 ms
1
100 ms
2
Logging
Capacity
24 days
12 days
58 hours
29 hours
Page 63/63
Need help?
Do you have a question about the iLog Series and is the answer not in the manual?
