Channel and Sensor Specifications:

Connections:
Channels:
Resolution:
Accuracy:

Measure Resistance:

Select "Resistance" equation to measure resistance.

Measure Temperature:

The simple way to measure temperature is by using built-in "Temperature" equation. You
select "Temperature" in "Equation" column:
Then you need to change temperature coefficient values by clicking "Change Coefficients"
button in "Action" column:
In the pop-up dialog enter new temperature coefficient values and click "OK" button.
iLog Data Loggers User's Manual
Plugeable terminal block for one external channel, excitation
controls and alarm outputs
CH0: on-board thermistor (-40 ~ +70°C (-40 to + 158°F).
CH1 external thermistor/resistor
0.0018%
Thermistor channel: ± 0.2°C(0°C ~ 70°C)
External channel: ± 0.2% FSR @ 25°C
